ZTE 3950-52TD switch supports 48 10/100 Base-T Ethernet ports, 4 1GE optical ports.
The ZXR10 3950 series all gigabit intelligent routing switches are layer-3 box-type switches developed for enterprises. The switches provide high-density gigabit access and 1G uplink interfaces that are capable of layer-2 switching and layer-3 routing. With various security and reliability mechanisms, the switches support Power over Ethernet (PoE). The ZXR10 3950 switches are applicable to convergency access and IDC gigabit access to intranets, providing reliable high-speed bandwidth solutions for enterprise customers.
The ZXR10 3950 switches are divided into the following types:
- ZXR10 3950-28TD
- ZXR10 3950-52TD
- ZXR10 3950-28PD
- ZXR10 3950-52PD
- ZXR10 3950-28SD
The front panel provides 48 GE RJ45 electrical interfaces that supports CAT 5 and enhanced CAT 5 twisted-pair cables.
The front panel provides four 1G interfaces, and supports optical modules with the 1G SFP+ interface and modules with the1G SFP interface.
The ZXR10 3950 uses special advanced core chips, which ensures service expansion and value-adding, extends its service life, and ensuresa high yield. Its compact structure needs a small space, and the dual power supply modules ensure high reliability and reduce the operation and maintenance costs. Besides, the ZXR10 3950 provides the following features:
- Large capacity and high service performance, ensuring high network upgrade and deployment efficiency
- Improving user experience in high-quality videos
- Integrated service platform
- Carrier-class reliability, improving the disaster recovery ability
- Considerable operation and maintenance design, reducing the operation and maintenance costs
- Environmentally-friendly design
|Dimensions (H × W × D)||43.6 mm×442 mm×440 mm|
|Power supply||AC: 100 V to 240 V, 50 Hz,DC : -38 V to -57 V|
|Power consumption||Typical power consumption: 39 W, Maximum power consumption: 74 W|
|Relative humidity||5% to 95% (non-condensing)|
|Environmental specification||Reduction of Hazardous Substances (RoHS)|
|Reliability||MTBF: > 400000 hours|
|MTtr: < 30 minutes|
|FCC Part 15 (CFR 47) Class A|
|EN 55022 Class A|
|ETSI EN 300 386|
|ICES-003 Class A|
|CISPR22 Class A|
|ICES-003 Class A|
|AS/NZS CISPR22 Class A|
|ITU-T K 20|
|ITU-T K 21|
|ITU-T K 44|
|UL 60950 3rd Edition|
|CSA C22.2 No. 60950 3rd Edition|
