5950-36CM
ZTE 5950-36CM switch supports 24 combo interfaces, 4 10G interfaces
ZTE
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (0)
Description
ZTE 5950-36CM switch provides 24 combo interfaces. The electrical interfaces support 10/100/1000 auto-sensing. The optical interfaces support 1000 Base-X and 100 Base-FX. The optical interfaces are SFP interfaces, 4 10G interfaces, and supports optical modules with the 10G SFP+ interface and modules with the 1G SFP interface.
| Name | Quantity | Description |
|---|---|---|
| 10/100/1000 Base-T Ethernet interface | 24 | The electrical interfaces support 10/100/1000 auto-sensing. The optical interfaces support 1000Base-X and 100Base-FX. The optical interfaces are SFP interfaces. |
| 10G optical interface | 4 | Fixed Ethernet optical interface, supporting optical modules with the 10G SFP+ interface and modules with the 1G SFP interface. The 100M optical module is not supported. |
| Console interface | 2 | One MiniUSB interface or RJ45 interface for service configuration management. Only either of the two interfaces can be used. |
| 10/100/1000 Base-T management interface. | 1 | It is used to boot devices and download version files. |
| USB interface | 1 | Type-A USB interface for reading and writing a USB disk. |
| Extended daughter card slot on the rear panel | 1 | Supported daughter cards, including: 2-port 40G optical interface daughter card 8-port 10G optical interface daughter card 8-port GE optical interface daughter card 2-port 40G stacking daughter card |
The ZXR10 5950-36CM provides the following indicators:
- One system status indicator (RUN/ALM) that indicates the device operation status, and one MNG indicator that indicates the operational status of debugging interfaces. 24 port indicators that indicate the status of 24 10/100/1000 Base-T ports. Each port corresponds to one indicator.
- 24 port indicators that indicate the status of 24 1000Base-X/100Base-FX ports. Each port corresponds to one indicator.
- 4 port indicators that indicate the status of 4 10G optical interfaces. Each port corresponds to one indicator.
- The power supply indicator PWR indicates the operational status of power supply.
- The fan indicator FAN indicates the operational status of the fan.
| Item | 5950-36CM |
| The ZXR10 5260-C switches are divided into the following types | The ZXR10 5950 switches are divided into the following types:ZXR10 5950-60TM
ZXR10 5950-36TM ZXR10 5950-60PM ZXR10 5950-36PM ZXR10 5950-36CM |
| 10/100/1000 Base-T Ethernet interface | 24 |
| 10G optical interface | 4 |
| Console interface | 2 |
| 10/100/1000 Base-T management interface. | 1 |
| USB interface | 1 |
| Dimensions (H × W × D) | 43.6 mm×442 mm×440 mm |
| Weight | ≤7.7kg |
| Power Supply | AC: 100 V to 240 V, 50 Hz to 60 Hz DC : -40 V to -57 V |
| Power consumption | Typical power consumption: 39 WMaximum power consumption: 84 W |
| Ambient temperature | Long term: -5°C to +50°CStorage temperature: -40°C to +70°C |
| Relative humidity | 5% to 95% (non-condensing) |
| Switching capacity | 288 Gbps |
| Packet forwarding rate | 216 Mpps |
| Memory | 2 GB |
| Environmental specification | Reduction of Hazardous Substances (RoHS) |
| Reliability | MTBF: > 400000 hoursMTTR: < 30 minutes
EMC: FCC Part 15 (CFR 47) Class A EN 55022 Class A ETSI EN 300 386 EN55024 ICES-003 Class A IEC 61000-3-2 IEC 61000-3-3 CISPR22 Class A CISPR24 ICES-003 Class A AS/NZS CISPR22 Class A IEC61000-4-2 ITU-T K 20 ITU-T K 21 ITU-T K 44 Safety: UL 60950 3rd Edition CSA C22.2 No. 60950 3rd Edition IEC 60950 EN 60950 EN60825-1 EN60825-2 IEC60825-1 IEC60825-2 |
