Description
CE6857F-48S6CQ overview
Huawei CE6857F-48S6CQ with 48 ports 10GE SFP+, 6 ports 100GE QSFP28, without fan and power modules is one of the Huawei CE6800 series switch
Offering high performance, high port density, and low latency, CloudEngine 6800 series switches enable enterprises and carriers alike to build cloud-oriented data center networks. Advanced data center features, high performance stacking technologies, and flexible airflow capabilities complete the series. CloudEngine 6800 is well suited to both the core and aggregation layers and is fully compatible with CloudEngine 16800 and 12800 series switches, enabling enterprises to build scalable, simplified, open, and secure networks.
Appearance of the CE6857F-48S6CQ
1 | Ground screw |
2 | Equipment serial number (ESN) |
3 | Console port |
4 | ETH management port (RJ45) |
5 | USB port |
6 | Fan slot 1 |
7 | Fan slot 2 |
8 | Fan slot 3 |
9 | Fan slot 4 |
10 | Power supply slot 1 |
11 | Power supply slot 2 |
12 | Forty-eight 10GE SFP+ Ethernet optical ports |
13 | Six 40GE/100GE QSFP28 Ethernet optical ports |
14 | Three port-side mounting holes for mounting brackets |
15 | Two middle mounting holes for mounting brackets |
16 | Equipotential bonding Ground screws for a ground cable with a two-hole OT terminal |
17 | Four power-supply-side mounting holes for mounting brackets |
Indicators on the CE6857F-48S6CQ1
1 | System status indicator |
2 | Stack master/slave indicator |
3 | ID indicator |
4 | Service port indicator (10GE SFP+ Ethernet optical port) |
5 | Service port indicator (40GE/100GE QSFP28 Ethernet optical port) |
Indicators on the CE6857F-48S6CQ2
6 | ETH management port indicator |
7 | USB-based deployment indicatorc |
Ports on the CE6857F-48S6CQ
Port | Connector Type | Description | Available Components |
---|---|---|---|
10GE SFP+ Ethernet Optical Port | LC | A 10GE SFP+ Ethernet optical port supports auto-sensing to 1000 Mbit/s, and can receive and send services at a rate of 1000 Mbit/s or 10 Gbit/s.
|
GE eSFP optical modules
GE SFP copper modules 10GE SFP+ optical modules |
40GE/100GE QSFP28 Optical Port | Depending on the optical module | A 40GE/100GE QSFP28 optical port sends and receives service traffic at 40 Gbit/s or 100 Gbit/s.
|
40GE QSFP+ optical modules
100GE QSFP28 optical modules |
Console Port | RJ45 | The console port is connected to a console for onsite configuration.
|
Console cable |
ETH Management Port | RJ45 | The ETH management port (RJ45) of a switch is connected to the network port of a configuration terminal or network management workstation to set up the onsite or remote configuration environment.
|
Category 5 or higher category cable |
USB Port | USB | A USB flash drive can be connected to the USB port for log backup, system software backup and uploading, or USB-based deployment. | USB 2.0-compliant USB flash drive. |
