DP32PDC1K6A1 overview

Huawei NetEngine 8000 M8 DP32PDC1K6A1 power interface board. This power module does not support hot swap, DC power module, and AC power module cannot be used at the same time.



Mapping products and versions

Product	Slot	Minimum Version Requirement
NetEngine 8000 M8	slot 11 to slot 12	V800R011C10



The appearance of the DP32PDC1K6A1





Indicators on the DP32PDC1K6A1

Silkscreen	Name	Color	Status	Description
PWR	Power supply status indicator	Green	Steady on	The power input is normal.
		–	Off	The power module is switched off or the hardware of the power module is faulty.



Ports on the DP32PDC1K6A1

Port	Description
NEG (-)	-48 V/-60 V power input interface
RTN (+)	BGND power input interface



Item	DP32PDC1K6A1
Dimensions without packaging (H x W x D) [mm(in.)]	11 mm × 53.5 mm × 208.8 mm (0.43 in. x 2.11 in. x 8.22 in.)
Weight without packaging [kg(lb)]	0.2 kg (0.44 lb)
Number of inputs	1
Rated input voltage [V]	-48 V/-60 V
Input voltage range [V]	-40 V to -72 V
Maximum input current [A]	40 A
Rated output voltage [V]	-48 V/-60 V
Rated output current [A]	40 A
Rated output power [W]	1600 W
Power supply efficiency (25°C)	99%
Power dissipation Mode	Air cooling
Type of power cables	10 mm2
