ZTE ZXR10 8912E/8908E/8905E/8902E switches H1XF8A card provides eight 10 GE optical interfaces and supports full wire-speed MPLS forwarding


SKU: 2009131 Category:


H1XF8A overview

The H1XF8A card provides eight 10 GE optical interfaces. It is applicable to the ZXR10 8912E/8908E/8905E/8902E switches and supports full wire-speed MPLS forwarding.
The H1XF8A card provides the following functions:


• Large switching capacity
It provides four 10 GE SFP+ optical interfaces and supports full wire-speed MPLS forwarding.


• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.


• EPLD online upgrade
The EPLD of the H1XF8A module provides the online upgrade function by simulating the JTAG interface.


• JTAG test
The H1XF8A module connects to main chips of line interface cards through a daisy chain to conduct the JTAG test.


• Intelligent detection
Temperature, voltage, and power consumption monitoring circuits are designed on the module to implement real-time monitoring through the IIC bus.


• IPMC management and control unit
The IPMC of each line interface card connects to the IPMC of the MCS module through a bus to establish an intelligent platform management system.


• Synchronous Ethernet & IEEE 1588v2
It supports Synchronous Ethernet & IEEE 1588v2 time synchronization.

• Power supply management
A power management chip can control the power-on sequence of devices.

Parameter Specification
Silk screen name H1XF8A
Dimensions 374.61mm × 395.4mm × 40.3mm
Power consumption Power consumption after power-on: 64 W; Full-load power consumption: 68 W
CPU Capacity Dual-core CPU, CPU speed: 800 MHz
Memory Maximum capacity 1 GB


Attribute Specification
Connector Duplex LC
Optical Interface Attribute Determined by the selected SFP+ optical module
Operating mode Full duplex
Standard 10 GE, IEEE 802.3ae 10GBASE-R
Frame format Ethernet frame
Network protocol Ethernet
