H2XF48C

ZTE H2XF48C card is a 48-port 10GE SFP+ interface card. It provides 48 wire-speed SFP+ interfaces. This card can be applied to the full series of 8900E systems, and supports MPLS wire-speed forwarding. It is applicable to large-sized data centers and the backbone layer or convergence layer of an operator Metropolitan Area Network (MAN).

ZTE

SKU: 2009317 Category:

Description

H2XF48C overview

The H2XF48C card is a 48-port 10GE SFP+ interface card. It provides 48 wire-speed SFP+ interfaces. This card can be applied to the full series of 8900E systems, and supports MPLS wire-speed forwarding. It is applicable to large-sized data centers and the backbone layer or convergence layer of an operator Metropolitan Area Network (MAN).
The H2XF48C card provides the following functions:

• Large switching capacity
Forty-eight 10GE SFP+ interfaces are provided on the panel, with support for MPLS wire-speed forwarding and big table items.

• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.

• EPLD online upgrade
The EPLD of the H2XF48C module provides the online upgrade function by simulating the JTAG interface.

• JTAG test
The H2XF48C module connects to main chips of line interface cards through a daisy chain to conduct the JTAG test.

• Intelligent detection
Temperature, voltage, and power consumption monitoring circuits are designed on the module to implement real-time monitoring through the IIC bus.

• IPMC management and control unit
The IPMC of each line interface card connects to the IPMC of the MCS module through a bus to establish an intelligent platform management system.

• Power supply management
A power management chip can control the power-on sequence of devices.

Parameter Specification
Silk screen name H2XF48C
Dimensions 374.61 mm × 395.4 mm × 40.3 mm
Power consumption Static power consumption: about 56.38 W, operating power consumption with no optical modules: 103.60 W
CPU Capacity Dual-core CPU, CPU speed: 1.2 GHz
Memory Maximum capacity 2 GB



Port Type Feature Description
CFP2 Complies with IEEE 802.3ae 10GBASE-R
