Huawei AR651U-A4

Huawei AR651U-A4

Huawei AR651U-A4, 2*GE combo WAN, 8*GE LAN, 1*USB2.0, 1*HDD, 1*MIC slot, 50010484

Huawei

12 Months

SKU: 2014335 PN: 50010484 Category:

Description

Huawei AR651U-A4, 2*GE combo WAN, 8*GE LAN, 1*USB2.0, 1*HDD, 1*MIC slot, 50010484



Basic information about the AR651U-A4

Item Details
Description AR651U-A4, 2*GE combo WAN, 8*GE LAN, 1*USB2.0, 1*HDD, 1*MIC slot
Part Number 50010484
Model AR651U-A4
First supported version V300R019C10
Remarks

Part number of the AR651U-A4-L4EA equipped with the 1LTE4-EA card: 02351WGP (supported in V300R003C00 to V300R019C00 versions)

Part number of the AR651U-A4-L6EA equipped with the 1LTE6-EA card: 02351WGN (supported in V300R003C00 to V300R019C00 versions)

Part number of the AR651U-A4: 50010484 (supported in V300R019C10 and later versions)

The routers manufactured after March 31, 2021 support only V300R019C13 and later versions.



Item Specification
Installation type
  • Rack
  • Work bench
  • Against the wall
Dimensions without packaging (H x W x D) [mm(in.)]
  • Basic dimensions (excluding the parts protruding from the body): 44.0 mm x 300.0 mm x 220.3 mm (1.73 in. x 11.8 in. x 8.67 in.)
  • Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.0 mm x 300.0 mm x 224.7 mm (1.73 in. x 11.8 in. x 8.85 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 110 mm x 435 mm x 360 mm (4.33 in. x 17.13 in. x 14.17 in.)
Chassis height [U] 1 U
Weight with packaging [kg(lb)] 2.89 kg (6.35 lb)
Weight without packaging [kg(lb)] 1.92 kg (4.23 lb)
CPU 1.4 GHz, 4 Cores
Memory 4 GB
NAND Flash 1 GB
Hard disk

SATA 2.5-inch hard drive is supported.

NOTE:

The SSD-Sata240G hard disk (BOM: 02312SEU) is recommended.

Console port RJ45
RTC Supported
Maximum power consumption [W] 35 W
Power supply mode AC external
Number of power modules 1
Rated input voltage [V] 100 V to 240 V, 50 Hz/60 Hz
Input voltage range [V] 90 V to 264 V, 47 Hz to 63 Hz
Maximum input current [A] 3 A
Maximum output power [W] 36 W
Type of fans Built-in
Number of fan modules 0
Heat dissipation mode Air cooling
Airflow direction Left to right
Extended slots (standard configuration) 1 x MIC
Redundant power supply Not supported
RPS input Not supported
PoE Not supported
Noise at normal temperature (acoustic power) [dB(A)] 41.9 dB(A)
Long-term operating temperature [°C(°F)]

0°C to 45°C (32°F to 113°F)

NOTE:

When the altitude is 1800 m-5000 m (5906 ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).

Storage temperature [°C(°F)] -40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity [RH] 5% to 95%, noncondensing
Long-term operating altitude [m(ft.)] < 5000 m (16404.2 ft.)
MTBF [year] 42.67 year
MTTR [hour] 2 hour
Availability 0.9999946496
