Metro 3000

Huawei STM-4/STM-16 level MSTP Metro 3000 subrack equipped with 1xPBU

SKU: 8672 Category:


Switching Capacity TDM: 60 Gbit/s (higher order), 20 Gbit/s (lower order)
Service  Slots 12 slots for processing boards and 8 slots for interface boards
Supported Interfaces MSTP  interfaces STM-16/4/1, E1/E3/E4/T1/T3, FE/GE, DDN, IMA/ATM, FEC/EFEC, SAN, Video
WDM interfaces 40-channel DWDM interfaces, compliant with ITU-T G.694.1
8-channel CWDM interfaces, compliant with ITU-T G.694.2
Power  Supply DC: -48V DC or -60V DC, AC: 220V/110V AC
Maximum Number of Services Supported by  a Single Subrack Service Interface Max Service Interface Max
STM-16 9 STM-4 36
STM-1 92 STM-1 (electrical) 38
E4 16 E3/T3 57
E1 252 T1 252
FE 88 GE 28
DDN(N×64K) 32 Framed E1 32
STM-1 ATM 28 STM-4 ATM 7
FC200 4 DVB-ASI 20
Clock Synchronization Line clock source
Tributary clock source
Two external clock inputs/outputs (2 MHz or 2 Mbit/s)
Auxiliary Interface Orderwire interface, NNI connection interfaces
Management serial interface, serial interfaces, 64 kbit/s codirectional data channel, 10M/100M NM interface,commissioning interface
Alarm interface, Cabinet alarm indicator interface
Mechanical Specifications
Dimensions(mm) 668 (H) x 530 (W) x 542 (D)
Weight(kg) 27 (empty subrack)

Additional information

Weight 42.0000 kg
Dimensions 66.8000 × 53.0000 × 54.2000 cm
