JL070A
Aruba 2530 Switch Series JL070A supports 8 RJ-45 autosensing 10/100 PoE+ ports
Aruba
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (0)
Description
JL070A overview
Aruba 2530 Switch Series JL070A supports 8 RJ-45 autosensing 10/100 PoE+ ports .
The Aruba 2530 Switch Series provides cost-effective, reliable and secure access layer connectivity for enterprises, branch offices and small and midsize businesses.
These fully managed switches deliver Layer 2 capabilities with enhanced access security, traffic prioritization, sFlow, and IPv6 host support. Right size deployment is available with a range of Gigabit and Fast Ethernet models including compact and fanless models
which are ideal for use in quiet work spaces. PoE+ models deliver up 370W to power access points, IP phones and cameras.
The Aruba 2530 Switch Series is easy to deploy, use and manage using Aruba AirWave or Aruba Central. Aruba ClearPass offers Network Access Control and external captive portal support. The switches include a Limited Lifetime Warranty.
JL070A features
- Wired and Wireless Support
- Quality of Service (QoS)
- Simplified Configuration and Management
- Connectivity
- Layer 2 switching
- Security
- Convergence
- Resiliency and high availability
- Product architecture
- Flexibility
- Warranty and support
Item |
JL070A |
I/O ports and slots | 8 RJ-45 autosensing 10/100 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+); Media Type: Auto-MDIX; Duplex: half or full 2 dual-personality ports; each port can be used as either an RJ-45 10/100/1000 port (IEEE 802.3 Type 10BASE-T; IEEE 802.3u Type 100BASE-TX; IEEE 802.3ab 1000BASE-T Gigabit Ethernet) or as a SFP slot (for use with SFP transceivers) ports 1 dual-personality (RJ-45 or USB micro-B) serial console port |
100 Mb Latency | < 1.3 µs (LIFO 64-byte packets) |
1000 Mb Latency | < 1.3 µs (LIFO 64-byte packets) |
Switching capacity | 5.6 Gbps |
MAC address table size | 16000 entries |
Operating temperature | 32°F to 113°F (0°C to 45°C) |
Operating relative humidity |
15% to 95% @ 104°F (40°C), noncondensing |
Nonoperating/Storage temperature |
-40°F to 158°F (-40°C to 70°C) |
Nonoperating/Storage relative humidity |
15% to 90% @ 149°F (65°C), noncondensing |
Altitude | up to 10,000 ft (3 km) |
Acoustic | Power: 0 dB, Pressure: 0 dB |
Dimensions | 10(w) x 9.68(d) x 1.75(h) in (25.4 x 24.59 x 4.45 cm) (1U height) |
Weight | 4.65 lb (2.11 kg) |
