RPTH-20XGE-SFP+
ZTE RPTH-20XGE-SFP+ physical line interface unit H supports 20-port 10GE SFP+
ZTE
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (0)
Description
RPTH-20XGE-SFP+ overview
The RPTH-20XGE-SFP+ daughter card provides the following functions:
- Provides twenty 10 gigabit Ethernet interfaces supporting the LAN and WAN functions.
- Provides the function for storing physical information such as the daughter card ID, delivery date, daughter card version,and repair records.
- Provides the key chip temperature detection function.
- Provides an SJTAG interface for the network processing unit for online download and production test.
- Single port supports LAN/WAN or XGE/GE function switching.
| Attribute | Description |
|---|---|
| Connector type | Duplex LC |
| Optical interface attribute | Determined by the selected SFP+ optical module |
| Operating mode | Full duplex |
| Standard | 10GBASE-ER, 10GBASE-SR, 10GBASE-LR |
| Supported link protocol | Ethernet frame |
| Network protocol | IP |
| Item | Description |
|---|---|
| Silk screen name | RPTH-20XGE-SFP+ |
| Dimensions (Width × Height × Depth) | 37.1 mm ×188.8 mm ×183.7 mm |
| Power consumption | 58 W |
| Thermal load | 187.92 BTU/Hour |
| Weight | 0.5 kg |
| Rate | 10.3125 Gbps |
