Description
W2PSA1150 overview
Huawei W2PSA1150 supports 1150 W AC PoE Power Module apply to S5700/5710 series switch.
Product support for a 1150 W AC PoE power module
| Power Module Name |
Product Support |
| W2PSA1150 |
S5710-52C-PWR-EI, S5720-52X-PWR-SI-ACF, S5720-56C-PWR-HI-AC, S5710-108C-PWR-HI, S5720-56C-PWR-EI-AC1, S5730-68C-PWR-SI, S5730S-68C-PWR-EI, S5730-36C-PWH-HI, S5730-44C-PWH-HI, S5730-60C-PWH-HI, S5730-68C-PWH-HI |
Functions of a 1150 W AC PoE power module
| Function |
Description |
| PoE power supply |
Provides a maximum of 785.4 W PoE power. |
| Input protection |
Provides protection against input overcurrent and input undervoltage. |
| Output protection |
Provides protection against output overvoltage, output overcurrent, and output short-circuit. |
| Overtemperature protection |
When the temperature of the power module exceeds a specified threshold (70°C), the power module stops supplying power. When the temperature falls into the normal range, the power module automatically resumes power supply. |
| Hot swapping |
Supported |
Technical specifications of a 1150 W AC PoE power module
| Item |
Description |
| Dimensions (H x W x D) |
41.4 mm x 100.0 mm x 281.0 mm (1.63 in. x 3.9 in. x 11.1 in.) |
| Weight |
< 1.6 kg (3.53 lb) |
| Rated input voltage |
100 V AC to 240 V AC, 50/60 Hz |
| Maximum input voltage |
90 V AC to 290 V AC, 45 Hz to 65 Hz |
| Input current |
10 A |
| Maximum output current |
- +12 V: 29.17 A
- -53.5 V: 14.95 A
|
| Maximum output power |
- PoE: 785.4 W (220 V)/446.6 W (110 V)
- Total: 1150 W (220 V)/800 W (110 V)
|
| Part number |
02130984 |
