ZTE ZXHN F623(USED)
ZTE ZXHN F623(USED) GPON Terminal with 1*GE+3*FE+1*POTS+1*USB+2.4G WIFI
ZTE
In Stock
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (0)
Description
ZTE ZXHN F623 overview
The ZTE ZXHN F623 is a high quality network gateway. It supports many L3 functions to create a smart home network. And it provides a high quality broadband connection to the Internet through a GPON optical interface, while maintaining stable operation of services such as VoIP and IPTV.
The ZTE ZXHN F623 terminal has a Wi-Fi wireless network interface, which will allow you to share the connection more easily with other devices without using additional cables.
ZTE ZXHN F623 is equipped with the following ports:
4 x Ethernet port, of which 1 supports Gigabit Ethernet, used to connect wired devices, providing a stable and efficient connection,
1 x POTS port allows you to connect a phone without the need to split additional cable,
1 x USB will allow you to connect devices such as storage media to share files on the network.
| ZTE ZXHN F623(USED) | Specification |
| Working environment | Operating temperature: 0ºC to 40ºC |
| Environment humidity: 5% to 95% (noncondensing) | |
| Typical power consumption | 10 W |
| Power specifications | Power adapter input: 100 to 240 V AC, 50–60 Hz |
| System power supply: 12 VDC,1.5 A | |
| WLAN | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Support IPv4 or IPv6 | IPv4 and IPv6 |
| Network-side Port | GPON |
| User-side Ports | 1 x POTS + 1 x GE + 2.4GWi-Fi + 1 x USB + 3 x FE |
| Indicators | POWER/PON/LOS/WLAN/TEL/LAN1/LAN2/LAN3/LAN4/USB |
