NE8000 CR5D00LAXF91(10*Port 10GE/GE LAN/WAN-SFP+ MACsec Physical Interface Card(PIC))



    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

Basic information about the CR5D00LAXF91

Item Details
Description 10-Port 10GE/GE LAN/WAN-SFP+ MACsec Physical Interface Card(PIC)
Card type Interface Card
Part Number 03033BLN
Model CR5D00LAXF91
Silkscreen 10x10GE-SFP+



Mappings between CR5D00LAXF91 and product models

Product Sub-Series
Product Model
First Supported Version
Limitations
NetEngine 8000 M14 CR8B0BKPACC2 NetEngine 8000 M V800R012C00 Long-term operating temperature: -40 °C to 65 °C (-40 °F to 149 °F)
NetEngine 8000 M14 CR8B0BKPDCC1 NetEngine 8000 M V800R012C00 Long-term operating temperature: -40 °C to 65 °C (-40 °F to 149 °F)
NetEngine 8000 M14 CR8B0BKPACC1 NetEngine 8000 M V800R012C10 –
NetEngine 8000 M8 CR8BM8BKPDC1 NetEngine 8000 M V800R011C10 Long-term operating temperature: -40 °C to 65 °C (-40 °F to 149 °F)
NetEngine 8000 M8 CR8BM8BKPAC1 NetEngine 8000 M V800R012C00 Long-term operating temperature: -40 °C to 65 °C (-40 °F to 149 °F)





Show More Show Less
Item CR5D00LAXF91
Basic function Occupies one flexible card slot. Supports the line-rate receiving and transmitting on ten 10GE/GE interfaces and supports SFP+/SFP optical modules on the interfaces.
Reliability and availability Support for hot swap.
Restrictions and remarks Ports 2–5 belong to a port group, and ports 6–9 belong to another one. In LAN/WAN switching, the mode of ports in a port group must be switched at the same time.
Breakout supported No
Interface rate auto-sensing supported Supports GE/10GE auto-sensing.
Dimensions without packaging (H x W x D) [mm(in.)] 19.8 mm x 193.8 mm x 209.3 mm (0.78 in. x 7.63 in. x 8.24 in.)
Weight without packaging [kg(lb)] 0.8 kg(1.76 lb)
Typical power consumption [W] 32.6 W
Typical heat dissipation [BTU/hour] 105.8 BTU/hour
Long-term operating temperature [°C(°F)] -40°C to 65°C(-40°F to 149°F)

Additional information

Brand

Huawei
Lead Time

3-5 days
Ship From

Shenzhen Warehouse
Item CR5D00LAXF91
Basic function Occupies one flexible card slot. Supports the line-rate receiving and transmitting on ten 10GE/GE interfaces and supports SFP+/SFP optical modules on the interfaces.
Reliability and availability Support for hot swap.
Restrictions and remarks Ports 2–5 belong to a port group, and ports 6–9 belong to another one. In LAN/WAN switching, the mode of ports in a port group must be switched at the same time.
Breakout supported No
Interface rate auto-sensing supported Supports GE/10GE auto-sensing.
Dimensions without packaging (H x W x D) [mm(in.)] 19.8 mm x 193.8 mm x 209.3 mm (0.78 in. x 7.63 in. x 8.24 in.)
Weight without packaging [kg(lb)] 0.8 kg(1.76 lb)
Typical power consumption [W] 32.6 W
Typical heat dissipation [BTU/hour] 105.8 BTU/hour
Long-term operating temperature [°C(°F)] -40°C to 65°C(-40°F to 149°F)
