LS5W2PSA0870 870 W PoE Power Module, Rectifier 15 A
Basic information about the LS5W2PSA0870
| Item | Details |
|---|---|
| Description | 870 W PoE Power Module, Rectifier 15 A |
| Part Number | 02310LGV |
| Model | LS5W2PSA0870 |
RPS1800 matching an 870 W PoE power module
| Power Module Name | Product Support |
|---|---|
| LS5W2PSA0870 | Supported only in the RPS1800 |
| Item | LS5W2PSA0870 |
|---|---|
| Dimensions (H x W x D) | 40.8 mm x 95.5 mm x 208.0 mm (1.61 in. x 3.76 in. x 8.19 in.) |
| Weight | < 1.5 kg |
| Rated input voltage | 220/110 V AC, 50/60 Hz |
| Maximum input voltage range | 200 V AC to 240 V AC (220 V rated voltage input)/100 V AC to 120 V AC (110 V rated voltage input), 47 Hz to 63 Hz |
| Input current | 4.7 A |
| Maximum output power |
|
Additional information
| Weight | 4.5000 kg |
|---|---|
| Dimensions | 27.0000 × 21.0000 × 8.0000 cm |
