S5735-L8P4X-IA1

0 Reviews Write a review
PN98011579
AvailabilityIn Stock
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Huawei S5735-L8P4X-IA1 switch supports 8 10/100/1000BASE-T ports, 4 10GE SFP+ ports, PoE+, 1 AC power fixed



Description

S5735-L8P4X-IA1 overview

This Huawei switch supports 8 10/100/1000BASE-T ports, 4 10GE SFP+ ports, PoE+, AC power

The S5735-L8P4X-IA1 has the same types of indicators as the S5735-L24P4X-A1. For details, see the S5735-L24P4X-A1.

The switch has a built-in AC power module and does not support pluggable power modules. The built-in power module can provide 124 W PoE power, which ensures full PoE power on 8 ports in compliance with 802.3af or on 4 ports in compliance with 802.3at.



S5732-H48UM2CC quick spec

8 10/100/1000BASE-T ports

4 10GE SFP+ ports

PoE+

AC power



S5735-L8P4X-IA1 appearance
1 Eight 10/100/1000BASE-T PoE+ ports
2 Four 10GE SFP+ ports
3 One console port
4 One USB port
5 One PNP button
6 Ground screw
7 AC socket
8 Jack for AC power cable locking strap
Item S5735-L8P4X-IA1
Power supply mode AC built-in
Rated input voltage [V] AC input: 100 V AC to 240 V AC, 50/60 Hz
Input voltage range [V] AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current [A] 3:00 AM
Memory 512 MB
Flash memory 512 MB
Console port RJ45
Eth Management port Not supported
USB Supported
RTC Not supported
RPS input Not supported
Service port surge protection [kV] Common mode: ±7 kV
Power supply surge protection [kV] ±6 kV in differential mode, ±6 kV in common mode
Types of fans Built-in
Heat dissipation mode Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction Air intake from left and front, air exhaustion from right
PoE Supported
Certification EMC certification
Safety certification
Manufacturing certification
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 300.0 mm x 220.0 mm (1.72 in. x 11.81 in. x 8.66 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 300.0 mm x 227.0 mm (1.72 in. x 11.81 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 110.0 mm x 435.0 mm x 360.0 mm (4.33 in. x 17.13 in. x 14.17 in.)
Chassis height [U] 1 U
Weight without packaging [kg(lb)] 2.23 kg (4.92 lb)
Weight with packaging [kg(lb)] 3.04 kg (6.7 lb)
Typical power consumption [W] 26.2 W
Typical heat dissipation [BTU/hour] 89.40 BTU/hour
Maximum power consumption [W] Without PoE: 33 W
Full PoE load: 178 W (PoE: 124 W)
Maximum heat dissipation [BTU/hour] Without PoE: 112.60
Full PoE load: 607.35
MTBF [year] 62.46 year
MTTR [hour] 2 hour
Availability >0.99999
Noise at normal temperature (acoustic power) [dB(A)] 42.2 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)] 30.5 dB(A)
Number of card slots 0
Number of power slots 0
Number of fans modules 1
Redundant power supply Not supported
Long-term operating temperature [°C(°F)] –40°C to +65°C (–40°F to +149°F) at an altitude of 0–1800 m (0–5906 ft.)
NOTE:
–40°C to –30°C (–40°F to –22°F): Stable port performance can be achieved only when at least two Ethernet electrical ports go Up.
Short-term operating temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
The device can work for a short period of time when the operating temperature is beyond the normal range, but the following conditions must be met:
The operating temperature can exceed 65°C (149°F) for a maximum of 96 consecutive hours in a year.
The total time when the operating temperature exceeds 65°C (149°F) in a year is less than or equal to 360 hours.
The number of times the operating temperature exceeds 65°C (149°F) is less than or equal to 15 in one year.
If any of the preceding conditions is not met, the device may be damaged or an unknown error may occur.
The maximum transmission distance of an optical module used for short-term operation cannot exceed 10 km.
Storage temperature [°C(°F)] –40°C to +75°C (–40°F to +167°F)
Long-term operating relative humidity [RH] 5% to 95%, noncondensing
Long-term operating altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)

Additional information

Brand

Huawei

Lead Time

3-5 days

Ship From

Shenzhen Warehouse

Item S5735-L8P4X-IA1
Power supply mode AC built-in
Rated input voltage [V] AC input: 100 V AC to 240 V AC, 50/60 Hz
Input voltage range [V] AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current [A] 3:00 AM
Memory 512 MB
Flash memory 512 MB
Console port RJ45
Eth Management port Not supported
USB Supported
RTC Not supported
RPS input Not supported
Service port surge protection [kV] Common mode: ±7 kV
Power supply surge protection [kV] ±6 kV in differential mode, ±6 kV in common mode
Types of fans Built-in
Heat dissipation mode Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction Air intake from left and front, air exhaustion from right
PoE Supported
Certification EMC certification
Safety certification
Manufacturing certification
Dimensions without packaging (H x W x D) [mm(in.)] Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 300.0 mm x 220.0 mm (1.72 in. x 11.81 in. x 8.66 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 300.0 mm x 227.0 mm (1.72 in. x 11.81 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)] 110.0 mm x 435.0 mm x 360.0 mm (4.33 in. x 17.13 in. x 14.17 in.)
Chassis height [U] 1 U
Weight without packaging [kg(lb)] 2.23 kg (4.92 lb)
Weight with packaging [kg(lb)] 3.04 kg (6.7 lb)
Typical power consumption [W] 26.2 W
Typical heat dissipation [BTU/hour] 89.40 BTU/hour
Maximum power consumption [W] Without PoE: 33 W
Full PoE load: 178 W (PoE: 124 W)
Maximum heat dissipation [BTU/hour] Without PoE: 112.60
Full PoE load: 607.35
MTBF [year] 62.46 year
MTTR [hour] 2 hour
Availability >0.99999
Noise at normal temperature (acoustic power) [dB(A)] 42.2 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)] 30.5 dB(A)
Number of card slots 0
Number of power slots 0
Number of fans modules 1
Redundant power supply Not supported
Long-term operating temperature [°C(°F)] –40°C to +65°C (–40°F to +149°F) at an altitude of 0–1800 m (0–5906 ft.)
NOTE:
–40°C to –30°C (–40°F to –22°F): Stable port performance can be achieved only when at least two Ethernet electrical ports go Up.
Short-term operating temperature [°C(°F)] –40°C to +70°C (–40°F to +158°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate [°C(°F)] When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
The device can work for a short period of time when the operating temperature is beyond the normal range, but the following conditions must be met:
The operating temperature can exceed 65°C (149°F) for a maximum of 96 consecutive hours in a year.
The total time when the operating temperature exceeds 65°C (149°F) in a year is less than or equal to 360 hours.
The number of times the operating temperature exceeds 65°C (149°F) is less than or equal to 15 in one year.
If any of the preceding conditions is not met, the device may be damaged or an unknown error may occur.
The maximum transmission distance of an optical module used for short-term operation cannot exceed 10 km.
Storage temperature [°C(°F)] –40°C to +75°C (–40°F to +167°F)
Long-term operating relative humidity [RH] 5% to 95%, noncondensing
Long-term operating altitude [m(ft.)] 0-5000 m (0-16404 ft.)
Storage altitude [m(ft.)] 0-5000 m (0-16404 ft.)
