TN11D4001

40-channel Demultiplexing Board(C_Even,196.00THz~192.10THz)

Huawei

SKU: 03030ETE Category:

Description

Huawei OSN6800 OSN8800 40-channel Demultiplexing Board(C_Even,196.00THz~192.10THz,100GHz,Thermal AWG,LC)

Optical Interface Parameter
Adjacent channel spacing(GHz) 100
Insertion loss(dB) <= 6.5
Reflectance(dB) < -40
Operating wavelength range(nm) 1529-1561
Adjacent channel isolation(dB) > 25
Non-adjacent channel isolation(dB) > 25
Polarization dependent loss(dB) <= 0.5
Temperature characteristics(nm/°C) < 0.002
Maximum channel insertion loss difference(dB) <= 3
-1 dB bandwidth(nm) >= 0.2
-20 dB bandwidth(nm) < 1.4
Mechanical Specifications
Dimensions(mm) 76.2(W) x 220(D) x 264.6(H)
Weight(kg) 2.2
