TNS7N402 overview

TNS7N402 supports 2*100Gbit/s Universal Line Service Processing Board applied to Huawei OptiX OSN 9800 U64/U32/U16.

The TNS7N402 board is a hybrid line board and supports a mixture of OTN, SDH services.

The TNS7N402 board processes and converts the received service signals into two OTU4 signals.  The OTU4 signals are carried over ITU-T G.694.1-compliant DWDM wavelengths.

The TNS7N402 board uses coherent receiving technologies and applies to coherent systems.

The optional versions of TNS7N402 are TNS4N402, TNS2N402, TNS8N402, TNS9N402.

Appearance of the TNS7N402

Appearance of the TNS7N402

Valid slots for the TNS7N402

Product Valid Slots
OptiX OSN 9800 U32 Standard subrack IU1-IU32
OptiX OSN 9800 U32 Enhanced subrack IU1-IU32
OptiX OSN 9800 U64 Standard subrack IU1-IU64
OptiX OSN 9800 U64 Enhanced subrack IU1-IU64
OptiX OSN 9800 U16 Subrack IU1-IU14



Item TNS7N402
OTN functions
  • Supports the OTU4 interface on the WDM side.
  • Supports the OTN frame format and overhead processing defined in ITU-T G.709.
  • OTU4 layer: supports SM overhead processing.
  • ODUk (k = 0, 1, 2, 2e, 3, 4, flex) layer: supports PM and TCM overhead processing, and non-intrusive monitoring of PM and TCM overheads.
WDM specification Supports ITU-T G.694.1-compliant DWDM specifications.
Tunable wavelength function The board supports tunable wavelengths of WDM-side optical signals in Super C band (1524 nm to 1573 nm).
PRBS test function Supports the PRBS function on the WDM side.
FEC coding Supports SDFEC2 encoding

NOTE:

Boards that use different FEC modes cannot interconnect with each other.

Alarm and performance event monitoring
  • Monitors BIP8 bytes (Bursty mode) to help locate line failures.
  • Monitors parameters such as the bias current, temperature, and optical power of the laser.
  • Monitors OTN alarms and performance events.
Latency measurement The board supports latency measurement in the WDM-side optical port direction (upstream direction). When higher-order ODU4 cross-connections are created on the line board, TCM section latency measurement is supported for higher-order ODU4 channels. When lower-order ODUk cross-connections are created on the line board, PM/TCM section latency measurement is supported for higher-order ODU4 channels, and TCM section latency measurement is supported for lower-order ODUk channels.
Test frame Not supported
Physical clock Supported (ODU0/ODU1/ODU2/ODU2e/ODU3/ODUflex)
IEEE 1588v2 Not supported
ITU-T G.8275.1 Not supported
ITU-T G.8273.2 Not supported
Electrical-layer ASON Supported
Optical-layer ASON Supported

NOTE:

Only ASON without optical parameters is supported in high SOP mode.

Protection schemes
  • Supports ODUk SNCP.
  • Supports tributary SNCP protection.
  • Supports intra-board 1+1 protection (when working with the OLP or DCP board).

NOTE:

When the cross-connect granularity is ODUflex, the board does not support tributary SNCP protection.

Loopback WDM-Side Loopback Supported
Channel Loopback ODUk (k = 0, 1, 2, 2e, 3, or flex) channel loopbacks
ESC Supported
Specifications for Optical Modules
Board Optical Modules Service type Optical Module Type Position
N402/N404 100000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, SLH+, T50)-100G CFP Specifications OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, SLH, T51)-100G CFP Specifications OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, SLH, high optical power, T51)-100G CFP Specifications OTU4 Pluggable Optical Module WDM-Side
N402/N404 55000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, ULH, T52)-100G CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 40000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, LH, T53)-100G CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, wDCM, ULH, T61)-100G CFP Specifications OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2, wDCM, ULH, high optical power, T61)-100G CFP Specifications OTU4 Pluggable Optical Module WDM-Side
N402/N404 16000ps/nm-Extended C band-Tunable Wavelength-ePDM-QPSK(SDFEC2 , wDCM, Metro+, T63)-100G CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 55000ps/nm-Extended C Band-Tunable Wavelength-ePDM-100G QPSK(SDFEC2, ULH, High optical power, T52)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 40000ps/nm-Extended C Band-Tunable Wavelength-ePDM-100G QPSK(SDFEC2, LH, High optical power, T53)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 16000ps/nm-Extended C Band-Tunable Wavelength-ePDM-100G QPSK wDCM(SDFEC2, Metro+, High optical power, T63)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Super C band-Tunable wavelength-ePDM-100G QPSK (SDFEC2, SLH, F51)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable wavelength-ePDM-100G QPSK(SDFEC2, SLH, A51)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Extended C band-Tunable wavelength-ePDM-100G QPSK wDCM(SDFEC2, LH, A62)-CFP OTU4 Pluggable Optical Module WDM-Side
N402/N404 100000ps/nm-Super C band-Tunable wavelength-100G QPSK(SDFEC2, SLH, T51)-CFP-PIN OTU4 Pluggable Optical Module WDM-Side
