ZXHN F660 V7.1

ZXHN F660 V7.1


ZTE ZXHN F660 V7.1 GPON Optical Network Terminal with 1*GE+3*FE+1*POTS+1*USB+WIFI, 5dBi


Shenzhen Warehouse

3-5 days

SKU: 9915 Category:
View cart


ZTE ZXHN F660 V7.1 GPON Optical Network Terminal with 1*GE+3*FE+1*POTS+1*USB+WIFI, 5dBi

English firmware, English indicator, English interface description

Connector type SC/UPC

Overseas firmware

WiFi Standard: IEEE 802.11b、 IEEE 802.11g、 IEEE 802.11n

Can be configured by OLT or Web or NMS

Routing function supported

Packing dimension : 220*160*44mm

 F660 V7.1 Datasheet
 Item  ZXHN F660 V7.1
Working environment Operating temperature: 0ºC to 40ºC
Environment humidity: 5% to 95% (noncondensing)
Pressure environment: 0 to 106 kPa
Altitude: 3000 m
System power supply 11–14 VDC, 1 A
(length x width x height)
220mm x 160 mm x 44 mm

Additional information

Weight 1.5000 kg
Dimensions 14.0000 × 28.0000 × 4.0000 cm

2.4G WIFI ONT Comparation

Model F660 V7.1 HG8456M EG8141A5 HG6543C4 G-140W-MD
Brand ZTE Huawei Huawei Fiberhome Nokia
WIFI 5dBi 5dBi 5dBi 5dBi 2dBi

Q: Can I use F660 V7.1 to replace my F660 V8.0?

A: Yes, both models have the same ports.


Q: Can I use OMCI to manage F660 V8.0 via my ZTE C300?

A: Yes, this model supports ZTE OMCI protocol.


Q: Can I get some free samples for testing?

A: As the international shipping cost is high, we don’t send free samples, but the cost incurred by samples can be written off in the formal order.


Q: Can you print my logo on the shell and firmware?

A: Yes, we have OEM service available, for more detail please contact [email protected]

8 reviews for ZXHN F660 V7.1

  1. 5 out of 5

    Rafael Manuel Antonio

    Compré 30 piezas de ZTE F660 V8.0 para probar, y las ONTs funcionan muy bien. ¡Tal como se esperaba, seguiré comprándola!

  2. 5 out of 5


    40 samples have been received, tested with Huawei OLT, it turned out to be compatible, very cost-effective new ONT.

  3. 5 out of 5


    We purchased several samples, testing with unlocked Huawei OLT, which also bought from Telecomate.com, compatibility effect is good.

  4. 5 out of 5


    Estoy planeando comprar HG8546M, pero les pregunté a muchos proveedores y todos me dijeron que no estaban disponibles. Telecomate me dijo que la configuración de ZTE F660 V.8 y HG8645M es exactamente la misma, y ​también es compatible con la OLT de Huawei. Compré 5 unidades para probar, y era cierto. Me alegro mucho de encontrar como una ONT perfecta con bajo precio. Estoy listo para comprar en grandes cantidades.

  5. 5 out of 5


    Recently, the price of Huawei’s ONT has increased and the market inventory has decreased. I chose to use ZTE’s ONT. The price of ZTE is much lower for the same specifications. Telecomate.com’s technology helped me unlock the OLT remotely, allowing me to use Huawei’s OLT and support ZTE’s ONT. It is really amazing!

  6. 5 out of 5


    Since Huawei ONTs have been in short supply and prices have skyrocketed recently in the market, this ZTE ONT is a good alternative and more cost-effective.

  7. 4 out of 5


    Este modelo es muy popular en Argentina. Compramos 1000 F660 V8.0 para la OLT C300. Lo bueno es que la carcasa y el firmware son muy buenos, pero DHL es demasiado lento. Esperamos 2 semanas para recibir los productos.

  8. 5 out of 5


    Hemos recibido el primer envío, estamos muy satisfechos con el embalaje, la calidad y el tiempo de entrega del producto, esta semana estamos listos para realizar el segundo pedido.
