ZTE 5228E-PC switch supports 24 10/100/1000 Base-T Ethernet ports, 2 1000Base-FX Ethernet ports, AC power and the RPS power supply

Description

5228E-PC overview

ZTE 5228E-PC switch supports 24 10/100/1000 Base-T Ethernet ports, 2 1000Base-FX Ethernet ports, AC power and the RPS power supply

Introduction:

The ZXR10 5200E series switches are all-gigabit-port intelligent switch developed by ZTE Corporation. It provides gigabit-port access and support the Access Control List (ACL) function for ingress and egress. The ZXR10 5200E series switches are used in the access layers of educational networks, enterprise networks, political service networks, and carrier networks.

Depending on the slot quantity and capacity, the ZXR10 5200E series switches are divided into the following types:

  • ZXR10 5228E
  • ZXR10 5212E-C
  • ZXR10 5212E-PC
  • ZXR10 5228E-PC
  • ZXR10 5252E-PC
  • ZXR10 5228E-FI
Features:

The ZXR10 5200E series switches are environment-friendly and highly-reliable products, which are easy to maintain and bring satisfactory experience to customers.

  • Environment-friendly and energy-saving design
  • Advanced lightning-protection technology
  • Intelligent PoE supply
  • Powerful security platform
  • Abundant maintenance methods
Item ZXR10 5212E-PC
Dimensions (Height ×Width × Depth) 1.72 in. × 17.41 in. × 17.34 in. (43.6 mm ×442 mm ×440 mm)
Weight 14.33 lb <6.5 kg
Power supply Supports AC and RPS power supply. AC power supply Rated voltage range: 100 V–240 V AC, 50 Hz/60 Hz RPS power supply Rated voltage: +12 V DC
Power consumption < 760.9W (power consumption of the device in case of full load PoE output), and the maximum output power of PoE is 450 W (under normal operating conditions with 220 V AC input)
Ambient temperature Ambient temperature For long-term operations: -5 ℃ to +50 ℃ For short-term operations: -5 ℃ to +55 ℃ Storage temperature: -40 ℃ to +70 ℃
Humidity Relative humidity: 20%–90%, non-condensation
Memory size 128 MB
Port switch capacity 56 Gbps
Packet forwarding rate 42 Mpps
Capacity of MAC address table 16 K

Additional information

Brand

ZTE

Item ZXR10 5212E-PC
Dimensions (Height ×Width × Depth) 1.72 in. × 17.41 in. × 17.34 in. (43.6 mm ×442 mm ×440 mm)
Weight 14.33 lb <6.5 kg
Power supply Supports AC and RPS power supply. AC power supply Rated voltage range: 100 V–240 V AC, 50 Hz/60 Hz RPS power supply Rated voltage: +12 V DC
Power consumption < 760.9W (power consumption of the device in case of full load PoE output), and the maximum output power of PoE is 450 W (under normal operating conditions with 220 V AC input)
Ambient temperature Ambient temperature For long-term operations: -5 ℃ to +50 ℃ For short-term operations: -5 ℃ to +55 ℃ Storage temperature: -40 ℃ to +70 ℃
Humidity Relative humidity: 20%–90%, non-condensation
Memory size 128 MB
Port switch capacity 56 Gbps
Packet forwarding rate 42 Mpps
Capacity of MAC address table 16 K
