Shoto 6-GFM series 6-GFM-85 alve-regulated lead-acid battery



Description

6-GFM-85 Main Applications

  • Backup power for telecom and signal system
  • Military field, railway system, power system
  • UPS & emergency lighting system
  • Fire alarm and security system



Benefits

  • 10 years design life
  • Safely and reliably sealed
  • High energy density, low internal resistance and low discharge rate
  • Excellent charging acceptability and high sealed reaction effciency



Product Certificates

  • ISO 9001
  • ISO 14001
  • GB/T 28001
  • UL
  • CE

Technical Features

  • Adopt high strength ABS plastic, compact structure for battery container and valve, good impact resistance, and shock resistant performance;
  • Adopt multi-element alloy grids, low internal resistance, good corrosion resistance ability and charging acceptability;
  • New production process for plate, improve the utilization of active material;
  • High-purity electrolyte and special additives, low self-discharge;
  • Multi-layer seal technology and special seal glue, no leakage and no acid mist escape, safe and reliable.
6-GFM-85 Datasheet
Item 6-GFM-85
Normal Voltage 12V
Capacity 85Ah @ 10hr to 1.80v per cell @ 25°C(77°F)
Weight Approx. 26 kg (57.32 lbs)
Dimensions Length :286 mm Width :174 mm Height : 218 mm Total Height : 225 mm
Internal Resistance (full charged) Approx.4.6 mΩ@ 25°C(77°F)
Maximum Discharge Current 527 A(5sec)
Self Discharge @25°C(77 ℉) Less than 4% after 30 days storage
Operating Temperature Range Discharge:-40℃~50C(-40℉~122℉) Charge:-20℃~45C(4℉~113℉) Storage:-20℃~40C(4P~104℉)
Recommended operating Temperature 15℃~25℃(59℉~77℉)
Maximum Charging Current Limited 17 A
Charging Voltage @25°C(77°F) Float: 2.25 V/cell Temps coefficient -3 mV/°C Equalize: 2.35 V/cell
Terminal M6
Container Materials ABS/ABS VO (Optional)
Capacity Affected by Temperature 105%@40℃ 85% @0℃ 60%@-20℃
Desion L @25°C(77°F) 10 years

Additional information

Weight 11.0000 kg
Dimensions 60.0000 × 39.0000 × 15.0000 cm
