Description
8145V5 Overview
8145V5 Optical Network Terminal (ONT) an advanced solution designed to enhance your network connectivity experience.
The 8145V5 provides 4*GE, 1*POTS voice interface, 1*USB interface, 2.4G& 5G Wi-Fi.
Categories:OEM ONT
8145V5Hot
AvailabilityIn Stock
WarrantyUp to 36 months
8145V5 congfigure with 4GE+2USB+1POTS+2.4G/5G WIFI, similar to Huawei EG8145V5
| Device Specifications | |||
| Ports: | 4GE+2USB+1POTS+2.4G/5G WIFI | Operating temperature: | 0°C to +40C |
| Indicators: | POWE/PON/LOS/LAN/WLAN | Operating humidity: | 5%RH to 95%RH (non-condensing) |
| Power consumption | <18W | Weigh: | About 250g |
| Ratedin putrange: | 12V DC, 1.5A | Dimensions(H*W*D): | 30mm*190mm*140mm (with an external antenna) |
| RAM: | 2Gbit,DDR3 | FLASH: | 2Gbit,SPI NAND FLASH |
| InterfacesParameters | |||
| Optical port: | 1xGPON interface(SC/APC) | Tx Power: | 0.5~5dbm |
| Receiver sensitivity: | -27dBm | Wavelengths: | US1310nm, DS1490nm |
| Transmission Distance: | 0-20km | Transmit rate: | 2.488Gbps Downstream 1.244Gbps Upstream |
| User network interface: | 4xGE | WLAN: | IEEE 802.11 b/g/n/ac Antenna gain: 5dBi WPS |
| GPON | Class B+ | ||
| Function | |||
| Supported Services: | VolP, internet | VLAN: | 802.1Q, 802.1P, 802.1ad |
| VolP: | SIP/H.248, G.711/G.729, T.30/T.38 | L3 function: | DHCP server/Client/Relay, NAT |
| Wi-Fi authentication: | WPA-PSK, WPA2-PSK, WPA-PSK+WPA2-PSK | Wi-Fi: | WPS |
| Air Interface Rate： | 1200Mbps | Management: | Web Ul, TR069, ACS |
Additional information
| Lead Time | 3-5 days |
|---|---|
| Ship From | Shenzhen Warehouse |
