AT8
Huawei OSN1800V 8*port 2/4*wire and E&M processing board AT8, 03032CRD
Huawei
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (1)
Description
AT8 overview
Huawei OSN1800V 8*port 2/4*wire and E&M processing board AT8.
An AT8 board provides eight 2-/4-wire audio and E&M analog trunk ports that transparently transmit signaling and voice signals over a long distance.
An AT8 board transmits/receives and processes eight-channel analog voice signals or E&M signaling, and provides alarms and events for maintenance.
Version description of the AT8 board
Board |
Product Applicable-System Control Board-Initial Board Version Supported by System Control Board |
---|---|
TNW1AT8 |
1800 V-TNZ5UXCMS-V100R009C00 1800 V-TNZ5XCS-V100R019C10SPC300 1800 II Enhanced-TNZ2UXCL-V100R019C10SPC300 |
Item |
AT8 |
---|---|
Basic functions |
NOTE:
|
Port |
|
Service processing |
Receives/transmits and processes 2-wire/4-wire audio and E&M services. |
Overhead processing |
Supports the setting and query of the V5 and J2 bytes. |
Alarms and events |
Provides alarms and events for maintenance and fault locating. |
Maintenance features |
|
VC-12 SNCP |
Supported. |
E1 SNCP |
Supported. |
2M ASON |
When working with TNZ5UXCMS, the board supports this function. |
