CE5881-48T6CQ overview
CE5881-48T6CQ Huawei CE5800 switch 44GE RJ45,4*10GE RJ45 6*100G QSFP28
$0.00 Original price was: $0.00.Current price is: $0.00.
CE5881-48T6CQ Huawei CE5800 switch 44GE RJ45,4*10GE RJ45 6*100G QSFP28
CE5881-48T6CQ Huawei CE5800 switch 44GE RJ45,4*10GE RJ45 6*100G QSFP28
Item | CE5881-48T6CQ |
Memory | DRAM: 4 GB |
NOR Flash | 64 MB |
NAND Flash | 4 GB |
USB | Supported |
Power supply mode | AC |
DC | |
HVDC | |
Console port | RJ45 |
Downlink Service interface | 48*1000Base-T RJ45 (Only full-duplex is supported) |
Uplink Service interface | 4x10GE RJ45 and 6*100GE QSFP28 (Note: 1. 100GE interfaces are compatible with 40GE; 2. 100G interfaces do not support splitting into 4x25GE and 4x10GE; 3. Auto-negotiation of copper cables is not supported. 100GE and 40GE copper cables can only be used on stack ports and M-LAG peer-link ports.) |
Service port supporting the stack function | 10GE electrical ports and 100GE optical ports |
RTC | Supported |
Typical power consumption [W] | 292 W (50% throughput, 3 m Ethernet cables on 48 ports and QSFP28 high-speed cables on 6 ports, normal temperature, double power modules) |
307 W (50% throughput, 3 m Ethernet cables on 48 ports and short-distance optical modules on 6 ports, normal temperature, double power modules) | |
Typical heat dissipation [BTU/hour] | 996 BTU/hr (50% throughput, 3 m Ethernet cables on 48 ports and QSFP28 high-speed cables on 6 ports, normal temperature, double power modules) |
1047 BTU/hr (50% throughput, 3 m Ethernet cables on 48 ports and short-distance optical modules on 6 ports, normal temperature, double power modules) | |
Static power consumption [W] | 233 W |
Static heat dissipation [BTU/hour] | 795 BTU/hour |
Maximum power consumption [W] | 348 W |
Maximum heat dissipation | 1187 |
Number of power modules | 2 |
Redundant power supply | 1+1 backup |
Rated input voltage [V] | 600 W AC&240 V DC power module : AC: 100 V AC to 240 V AC, 50/60 Hz; DC: 240 V DC |
1000 W DC power module : -48 V DC to -60 V DC | |
1200 W high-voltage DC power module: 240 V DC to 380V DC | |
Input voltage range [V] | 600 W AC&240 V DC power module : AC: 90 V AC to 290 V AC, 45 Hz to 65 Hz; DC: 190 V DC to 290 V DC |
1000 W DC power module : -38.4 V DC to -72 V DC | |
1200 W high-voltage DC power module: 190 V DC to 400 V DC | |
Maximum input current [A] | 600 W AC&240 V DC power module : 8 A (100 V AC to 240 V AC); 4 A (240 V DC) |
1000 W DC power module : 30 A (-48 V DC to -60 V DC) | |
1200 W high-voltage DC power module: 8 A | |
Rated output power [W] | 600 W AC&240 V DC power module : 600 W |
1000 W DC power module : 1000 W | |
1200 W high-voltage DC power module: 1200 W | |
Certification | Safety standards compliance |
EMC standards compliance | |
Environmental standards compliance | |
Power supply surge protection [kV] | AC: 6 kV in common mode and 6 kV in differential mode |
DC: 4 kV in common mode and 2 kV in differential mode | |
HVDC: 4 kV in common mode and 2 kV in differential mode | |
Types of fans | Pluggable |
Number of fans | 4 |
Redundant fans | The device supports 3+1 backup of fan modules that work in hot standby mode. The system can operate properly for a short time after a single fan module fails. You are advised to replace the faulty fan module immediately. |
Heat dissipation mode | Air cooling |
Airflow direction | Front-to-back or back-to-front, depending on the fan modules and power modules. |
Availability | 0.999995469 |
MTBF [year] | 49.15 years |
MTtr [hour] | 1.95 hours |
Noise at normal temperature (27°C, sound pressure) [dB(A)] | Front-to-back airflow: 49 dBA in average (maximum: 52 dBA) |
Back-to-front airflow: 50 dBA in average (maximum: 52 dBA) | |
Noise at high temperature (40°C, sound pressure) [dB(A)] | Front-to-back airflow: 69 dBA in average (maximum: 74 dBA) |
Back-to-front airflow: 67 dBA in average (maximum: 73 dBA) | |
Long-term operating altitude [m (ft.)] | ≤ 5000 m (16404 ft.) |
Long-term operating relative humidity [RH] | 5% RH to 95% RH, noncondensing |
Long-term operating temperature [°C (°F)] | 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
Storage altitude [m (ft.)] | < 5000 m (16404 ft.) |
Storage relative humidity [RH] | 5% RH to 95% RH, noncondensing |
Storage temperature [°C (°F)] | -40°C to +70°C (-40°F to +158°F) |
Brand | Huawei |
---|---|
CE Switch | |
Lead Time | 3-5 days |
