CE88-D8YS4DQ-H Huawei CE8800 switch supports 8 Port 25GE SFP28 and 4 Port 400GE QSFP-DD Interface Card

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

CE88-D8YS4DQ-H overview



CE88-D8YS4DQ-H Huawei CE8800 switch supports 8 Port 25GE SFP28 and 4 Port 400GE QSFP-DD Interface Card



CE88-D8YS4DQ-H Version mapping

Product Product Model First Supported Version Last Supported Version Unsupported Version
CloudEngine 8800 CE8865-4C (02355RTA) V300R023C10 – –
CloudEngine 8800 CE8865-4C (02355RTB) V300R023C10 – –
CloudEngine 8800 CE8865-4C (02355RTC) V300R023C10 – –



CE88-D8YS4DQ-H function and feature

Functions and Features CE88-D8YS4DQ-H
Basic function The card provides data packet processing and traffic management on four 400GE QSFP-DD optical ports and eight 25GE SFP28 optical ports.
Port split Supported
Hot swapping Supported
Service port stacking Not supported
Show More Show Less
Item CE88-D8YS4DQ-H
Typical power consumption [W] 70 W
Typical heat dissipation [BTU/hour] 238.8 BTU/hour
Static power consumption [W] 5 W
Static heat dissipation [BTU/hour] 17.1 BTU/hour
Maximum power consumption [W] 80 W
Maximum heat dissipation [BTU/hour] 273 BTU/hour
Dimensions without packaging (H x W x D) [mm (in.)] 41.7 mm x 206 mm x 181.3 mm (1.64 in. x 8.11 in. x 7.14 in.)
Dimensions with packaging (H x W x D) [mm (in.)] 110 mm x 310 mm x 293 mm (4.33 in. x 12.2 in. x 11.54 in.)
Weight without packaging [kg (lb)] 1.02 kg (2.25 lb)
Weight with packaging [kg (lb)] 1.35 kg (2.98 lb)

Additional information

Brand
Lead Time
Ship From
Warranty
Item CE88-D8YS4DQ-H
Typical power consumption [W] 70 W
Typical heat dissipation [BTU/hour] 238.8 BTU/hour
Static power consumption [W] 5 W
Static heat dissipation [BTU/hour] 17.1 BTU/hour
Maximum power consumption [W] 80 W
Maximum heat dissipation [BTU/hour] 273 BTU/hour
Dimensions without packaging (H x W x D) [mm (in.)] 41.7 mm x 206 mm x 181.3 mm (1.64 in. x 8.11 in. x 7.14 in.)
Dimensions with packaging (H x W x D) [mm (in.)] 110 mm x 310 mm x 293 mm (4.33 in. x 12.2 in. x 11.54 in.)
Weight without packaging [kg (lb)] 1.02 kg (2.25 lb)
Weight with packaging [kg (lb)] 1.35 kg (2.98 lb)
