CR8DIPU1T2C5
NetEngine 8000 M14 IPU CR8DIPU1T2C5(Integrated Network Processing Unit (IPU-1T2-A))
Huawei
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Reviews (0)
Description
Basic information about the CR8DIPU1T2C5
Item | Details |
---|---|
Description | Integrated Network Processing Unit (IPU-1T2-A) |
Card type | IPU |
Part Number | 03033NRF |
Model | CR8DIPU1T2C5 |
Silkscreen | IPU-1T2-A |
Mappings between CR8DIPU1T2C5 and product models
Product Sub-Series
|
Product Model
|
First Supported Version
|
Limitations
|
IDs of available slots
|
---|---|---|---|---|
NetEngine 8000 M14 | CR8B0BKPACC2 | NetEngine 8000 M V800R012C10 | – | 15,16 |
NetEngine 8000 M14 | CR8B0BKPDCC1 | NetEngine 8000 M V800R012C10 | – | 15,16 |
NetEngine 8000 M14 | CR8B0BKPACC1 | NetEngine 8000 M V800R012C10 | – | 15,16 |
Item | CR8DIPU1T2C5 |
---|---|
Basic function | Line-Rate capability: 1200 Gbit/s.
Supports switching, control, and clock management. Supports the board-level 1:1 backup function. Supports ultra-high-precision clock. |
Reliability and availability | Supports the hot swappable function.
Supports the board-level 1:1 backup function. |
Dimensions without packaging (H x W x D) [mm(in.)] | 34.78 mm x 354.4 mm x 209 mm(1.37 in. x 13.95 in. x 8.23 in.) |
Weight without packaging [kg(lb)] | 2.55 kg(5.62 lb) |
Typical power consumption [W] | 135.6 W |
Typical heat dissipation [BTU/hour] | 440 BTU/hour |
Long-term operating temperature [°C(°F)] | -20°C to +55°C (-4°F to 131°F); startup: ≥ –5°C (23°F) |
CPU | 8-core 1.5 GHz |
SDRAM | 8GB |
Flash memory | 64MB |
Storage | 4GB NandFlash |
