EG8080P
$490.00
Save $100Huawei OLT compatible EG8080P ONT, 8*GE (PoE and PoE+), 1*GPON/XG-PON/XGS-PON
3-5 days
Shenzhen Warehouse
- Description
- DATASHEET
- Comparation
- FAQ
- Download
- Reviews (2)
Description
The EG8080P utilizes Gigabit-capable Passive Optical Network (GPON) technology to provide ultra-broadband access for enterprise campuses. It also provides 8 Gigabit Ethernet (GE) ports to support Power over Ethernet (PoE) functions. The EG8080P provides ultra-broadband access for enterprise campuses and 8 Gigabit Ethernet (GE) ports to support Power over Ethernet (PoE) functions. It also features high-performance service forwarding capabilities with Voice over Internet Protocol (VoIP), Internet, and HD video services.
Huawei OLT compatible EG8080P 8*GE (PoE and PoE+) comes with 1xGPON/XG-PON/XGS-PON uplink
- PON Port:
1*GPON/XG-PON/XGS-PON
SC/UPC connector
GPON: downstream 2.488 and upstream 1.244
XG-PON: downstream 9.953 and upstream 2.488
XGS-PON: downstream 9.953 and upstream 9.953
Type B single-homing
Type B dual-homing (supported in Layer 2 forwarding)
- GE Electrical Port:
8 GE PoE and PoE+
RJ-45 connector
IEEE 802.3af and IEEE 802.3at
Port rate auto negotiation (10/100/1000 Mbit/s)
Configuration of the number of MAC addresses learned
Auto-MDI/MDIX
Ethernet port-based VLAN transparent transmission and VLAN filtering
| Item | EG8080P |
|
User-side Ports |
8*GE (PoE and PoE+) |
|
Network-side Ports |
1*GPON/XG-PON/XGS-PON |
|
Static power consumption |
11W |
|
Typical power consumption |
13W (PoE port without PD) |
|
Maximum power consumption |
15W (PoE port without PD) |
|
Maximum PoE output power |
120 W (supported by the system) |
|
Surge protection specifications |
GE port: common mode 4 kV; differential mode 0.5 kV. |
|
Dimensions (H × W × D) |
56 mm × 254 mm × 180 mm |
|
Operating temperature |
-40°C to +55°C |
|
Operating humidity |
5%RH to 95%RH, no condensing |
|
Power adapter input |
100 V to 240 V AC, 50 Hz/60 Hz |
|
System power supply |
56 V DC, 2.5A |
10GPON ONT Comparation
| Model | HN8255Q | HN8546X6 | HN8346V5 | HN8245Q | HN8145V | EG8080P |
| Ports | 4*GE + 1*10GE + 2*POTS + 2*USB | 4*GE+1*POTS+2*USB | 4*GE+1*POTS+2*USB | 4*GE+2*POTS+2*USB | 4*GE+1*POTS+1*USB | 8*GE (PoE and PoE+) |
| WIFI 2.4G/5G | 2.4G/5G | WIFI6 | 2.4G/5G | 2.4G/5G | 2.4G/5G | / |
| Symmetrical | Yes | No | No | No | No | Yes |
Q: Is the EG8080P compatible with a GPON board, like GPHF?
A: No, XGPON ONT can only work with an XGS-PON board or XGS-PON & GPON Combo board.
Q: is it symmetrical?
A: Yes, it is asymmetrical. The uplink rate and the download rate both are 10G.
Q: Does it support AX WiFi?
A: It comes with non-WiFi.
Q: Does EG8080P work with a Huawei home router?
A: Yes, there is no compatibility problem between ONT and the home router.
Q: Can I get a more economical price?
A: Price is not a problem, if your order quantity is large, you can negotiate with your technical sales manager.
Yolanda Sanchez –
Purchased one for testing and I am quited satisfied, but there is no bulk purchase plan as XGSPON has no large-scale commercial in our country for the time being.
Luis –
The EG8080P provides 8 Gigabit Ethernet (GE) ports to support power over ethernet (PoE) functions, which meets my needs very much.
