Huawei ES5D000X2S00 2-Port 10GE SFP+ Front Optical Interface Card

SKU: 8346 PN: 03020XEV Category:

Description

ES5D000X2S00 Card Overview



The ES5D000X2S00 provides two 10GE SFP+ optical ports for data access and line-rate switching. It can be installed in a front card slot of the switch models.



Applicable switch models:

Card Switch Model
ES5D000X2S00
  • S5700-28C-SI
  • S5700-52C-SI
  • S5700-28C-PWR-SI
  • S5700-52C-PWR-SI
  • S5700-28C-EI
  • S5700-52C-EI
  • S5700-28C-EI-24S
  • S5700-28C-PWR-EI
  • S5700-52C-PWR-EI
  • S5710-28C-LI
  • S5710-52C-LI
  • S5710-28C-PWR-LI
  • S5710-52C-PWR-LI



ES5D000X2S00 Version Mapping



The mapping between the ES5D000X2S00 card and software versions.

Card Model Software Version
ES5D000X2S00

NOTE:

After the display device command is executed, the PCB model of the card is displayed as ES510X2S.

V100R005C01 to V200R005C03

NOTE:

This module is not supported in V200R003C02 or V200R003C10.



The appearance of the ES5D000X2S00



The functions of the ES5D000X2S0
Function Description
Basic function Provides two 10GE SFP+ optical ports for data access and line-rate switching.
10GE port A 10GE port is often used as an uplink aggregation port on high-bandwidth and high-speed MANs or backbone networks. When an enterprise needs high-quality triple-play service, use the ES5D000X2S00 to provide access ports for downlink devices or networks. Different transmission distances can be supported by using SFP+ optical modules.



NOTE: When used on the S5710-C-LI, the 10GE SFP+ ports support the 10GE SFP+ and GE SFP optical modules. When used on the S5700-SI, the 10GE SFP+ ports support 10GE SFP+ optical modules, GE optical modules, and GE copper modules (applicable in V200R002C00 and later versions and used with shielded Ethernet cables), SFP+ copper cables (applicable in V200R002C00 and later versions), and AOC cables (applicable in V200R003C00 and later versions). When used on the S5700-EI, the 10GE SFP+ ports support 10GE SFP+ optical modules, SFP+ copper cables (applicable in V200R002C00 and later versions), and AOC cables (applicable in V200R003C00 and later versions).



Attributes of a 10GE SFP+ optical port

Attribute Description
Connector type LC/PC
Optical port attributes Depending on the optical module used (see GE eS​FP Optical Modules, GE-CWDM eSFP Optical Modules, GE-DWDM eSFP Optical Modules, GE SFP Copper Modules, 10GE SFP+ Optical Modules, and 10GE-CWDM SFP+ Optical Modules)
Standards compliance IEEE 802.3ae



Additional information

Weight 1.5000 kg
Dimensions 19.3000 × 16.5000 × 8.7000 cm
