FXSO12

Huawei OSN1800V 12*port FXS/FXO processing board FXSO12, 03032CRE

Huawei

3-5 days

Shenzhen Warehouse

SKU: 2012350 PN: 03032CRE Category:

Description

FXSO12 overview

Huawei OSN1800V 12*port FXS/FXO processing board FXSO12.

An FXSO12 board provides 12*FXS/FXO ports, and transmits or receives analog voice signals for voice sessions.

An FXSO12 board transmits or receives 12-channel analog voice signals, and provides alarms and events for maintenance.

Version description of the FXSO12 board

Board

Product Applicable-System Control Board-Initial Board Version Supported by System Control Board

TNW1FXSO12

1800 V-TNZ5UXCMS-V100R009C00

1800 V-TNZ5XCS-V100R019C10SPC300

1800 II Enhanced-TNZ2UXCL-V100R019C10SPC300

Item

FXSO12

Basic functions

  • Provides 12 FXS/FXO ports, which can be configured on the NMS.
    • FXS port TX Gain (dB): -12.0 to 0.0, in steps of 0.5.
    • FXS port RX Gain (dB): -6.0 to 5.0, in steps of 0.5.
    • FXO port TX Gain (dB): -16.5 to 13.5, in steps of 0.5.
    • FXO port RX Gain (dB): -16.5 to 11.0, in steps of 0.5.
  • Supports the BROSCHT function.

Port

  • External ports: DDN-1 to DDN-12, representing 12 external ports which always use timeslot 1, with port IDs 1 to 12, respectively.
  • Internal ports: 2M-1 to 2M-12, representing 12 E1 internal ports which use timeslots 1-15 and 17-31, with port IDs 65 to 76, respectively.

Service processing

Transmits/Receives and processes 12-channel 64 kbit/s signals.

Overhead processing

Supports the setting and query of the V5 and J2 bytes.

Alarms and events

Provides alarms and events for maintenance and fault locating.

Maintenance features

  • Supports warm and cold resets. The warm reset does not affect services.
  • Supports the query of the manufacturing information of the board.
  • Supports board voltage detection and alarm reporting.
  • Supports board temperature detection, alarm reporting, and performance statistics collection.
  • Hot board swapping.

VC-12 SNCP

Supported.

E1 SNCP

Supported.

2M ASON

When working with TNZ5UXCMS, the board supports this function.
