Juniper MX10BASE-T DC

Juniper MX10BASE-T DC

Juniper MX10BASE-T with MX10-T-DC DC chassis, timing support—includes dual power supplies, MIC-3D-20GE-SFP, 1 empty MIC slot, S-MX80-ADV-R, S-MX80-Q, and S-ACCT-JFLOW-IN-5G licenses. Power supply cable needs to be ordered separately.

SKU: 11865 Category:

Description

MX10BASE-T DC Overview

The compact, agile, and full-featured MX10 Universal Routing Platform is ideally suited for enterprise and service provider applications, and is optimized for space- and power-constrained facilities. It is equipped with Modular Interface Card (MIC) slots that permit flexible network connectivity, and a MS-MIC slot that optionally provides dedicated service support.

The MX10 is also software upgradeable to deliver higher performance, port density, and additional services. This investment protecting approach enables customers to increase bandwidth, subscriber, and services scale while minimizing upfront costs.

Juniper MX10BASE-T with MX10-T-DC DC chassis, timing support—includes dual power supplies, MIC-3D-20GE-SFP, 1 empty MIC slot, S-MX80-ADV-R, S-MX80-Q, and S-ACCT-JFLOW-IN-5G licenses. Power supply cable needs to be ordered separately.

System capacity 40 Gbps

Support 20*GE SFP ports

The MX10 has two front MIC slots and one rear MIC slot. The rear MIC slot only supports the MS-MIC.
MX10BASE-T DC Datasheet



 Item MX10BASE-T DC
Layout System capacity 40 Gbps
Slot orientation Horizontal
Mounting Front or center
Physical Specification Dimensions
(W x H x D)
17.5 x 3.5 x 23.46 in (44.5 x 8.9 x 59.6 cm)
Weight fully loaded 30 lb/13.7 kg
Weight unloaded NA
Routing Engine Default memory 8 MB boot flash; 4 GB on NAND flash storage; 2 GB of DDR2 RAM
Number of cores 1 core
Redundancy Components Power supplies and fans
Environmental Air flow Side to side [forced air]
Operating temperature 32° to 115° F (0° to 46° C) at sea level
Operating humidity 5% to 90%
Operating altitude 10,000 ft (3048 m)
Certifications NEBS – GR-63-Core Physical Protection
– GR-1089-Core:EMC and Electrical Safety
