Description
M601C Overview
ATV GPON TT919C Optical Network Terminal
GPON ONT, 1GE+CATV
ENG firmware, ENG interface
Connector type SC/APC
Tested compatible with Huawei/ZTE GPON OLT
Categories:Optical CATV, OEM ONT
M601C
AvailabilityIn Stock
WarrantyUp to 36 months
M601C OEM ONT with 1GE+CATV, compatibe with Huawei MA5600T MA5800 Series OLT
| Item | M601C |
| Network-side Port | GPON |
| User-side Ports | 1GE+CATV |
| Optical port | 1xGPON interface (SC/APC) Class B+ Tx Power: 0.5~5dbm Receiver sensitivity: -27dBm Overload optical power: -8dBm Connection Loss: ＜1dbm Total Optical Loss: ＜2dbm Operating Wavelength Range: TX-1310nm; RX-1490nm Transmission Distance: 0 ~ 20km |
| CATV port | Optical receiving wavelength: 1550nm Optical input range: -16dBm to +2dBm Output resistance: 75 ohms Optical reflection loss: 40 dB RF Frequency range: 40 MHz to 1000 MHz AGC: -12 dBm ~ 0dBm MER: ≥32dB@-11dBm |
| Weight | About 200 g |
Additional information
| Lead Time | 3-5 days |
|---|---|
| Ship From | Shenzhen Warehouse |
