ZTE ZXR10 8900E series switch S1XF12A card provides 12 10-GE optical interfaces


SKU: 2009023 Category:


S1XF12A overview

The S1XF12A card provides 12 10-GE optical interfaces. It is applicable to all the ZXR10 8900E series switches.
The S1XF12A card provides the following functions:

• Large switching capacity
It provides 12 10-GE SFP+ optical interfaces for wire-speed forwarding.
• Gigabit out-of-band communication
The MCS module communicates with the CPU of the card through this function, for example, downloading the CPU initialization information.
• EPLD online upgrade
The EPLD of the S1XF12A card provides the online upgrade function by simulating the JTAG interface.
• JTAG test
The S1XF12A card connects to main chips of line interface cards through a daisy chain to conduct the JTAG test.
• Intelligent detection
Temperature, voltage, and power consumption monitoring circuits are designed on the card to implement real-time monitoring through the IIC bus.
• IPMC management and control unit
The IPMC of each line interface card connects to the IPMC of the MCS module through a bus to establish an intelligent platform management system.
• Synchronous Ethernet
It supports Synchronous Ethernet time synchronization.
• Power supply management
A power management chip can control the power-on sequence of devices. A power management chip can control the power-on sequence of devices.
Attribute Specification
Connector Duplex LC
Technical specifications Depending on the type of SFP+ module used
Operating mode Full duplex
Standard IEEE 802.3ae 10 GBASE-R
Frame format Ethernet frame
Network protocol Ethernet


Parameter Specification
Silk screen name S1XF12A
Dimensions 374.61 mm × 395.4 mm × 40.3 mm
Power consumption Static power consumption: about 51.3 W Power consumption without any optical module: 60.7 W
CPU Capacity Dual-core CPU, CPU speed: 800 MHz
Memory Maximum capacity 1 GB
