S5735S-L24P4S-MA

0 Reviews Write a review
PN98010926
AvailabilityIn Stock
Campus Switch S5735S-L
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Original price was: $0.00.Current price is: $0.00.

Huawei S5735S-L24P4S-MA switch supports 24* 10/100/1000BASE-T ports, 4* GE SFP ports,  PoE+, 1* AC power fixed

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

S5735S-L24P4S-MA Overview



Huawei S5735S-L24P4S-MA  switch supports 24* PoE+ 10/100/1000BASE-T ports, 4* GE SFP ports,  1* AC power fixed

The Huawei S5735S-L24P4S-MA switch has a built-in AC power module and does not support pluggable power modules.

The Huawei S5735S-L24P4S-MA switch has no fans and uses natural heat dissipation.



S5735S-L24T4S-MA basic information



Item Details
Description S5735S-L24T4S-MA (24*10/100/1000BASE-T ports, 4*GE SFP ports, AC power)
Part Number 98010926
Model S5735S-L24T4S-MA



S5735S-L24T4S-MA appearance



1 24* PoE+ 10/100/1000BASE-T ports 2 4* 1000BASE-X GE SFP ports
3 One console port 4 One ETH management port
5 One USB port 6 One PNP button
7 Ground screw 8 Jack for AC power cable locking strap
9 AC socket – –
Show More Show Less
Huawei S5735S-L24P4S-MA switch

Item S5735S-L24P4S-MA
Memory (RAM) 1 GB
Flash 512 MB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF) 92.82 years
Mean time to repair (MTtr) 2 hours
Availability > 0.99999
Service port surge protection Common mode: ±7 kV
Power supply surge protection ±6 kV in differential mode, ±6 kV in common mode
Dimensions (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Weight (with packaging) 4.08 kg (9 lb)
Stack ports Any 10/100/1000BASE-T ports or 1000BASE-X ports (applicable in V200R019C10 and later versions)
RTC Not supported
RPS Not supported
PoE Not supported
Rated voltage range AC input: 100 V AC to 240 V AC, 50/60 Hz
High-Voltage DC input: 240 V DC
Maximum voltage range AC input: 90 V AC to 264 V AC, 47 Hz to 63 Hz
High-Voltage DC input: 190 V DC to 290 V DC
Maximum power consumption (100% throughput) 34 W
Typical power consumption (30% of traffic load) 28 W
Tested according to ATIS standard
Operating temperature -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Noise under normal temperature (27°C, sound power) Noise-free (no fans)
Relative humidity 5% to 95%, noncondensing
Operating altitude 0-5000 m (0-16404 ft.)
Certification EMC certification
Safety certification
Manufacturing certification
Part number 98010926


Additional information

Weight 5 kg
Dimensions 55 × 36 × 15 cm
Campus Switch

Huawei S5735S-L24P4S-MA switch

Item S5735S-L24P4S-MA
Memory (RAM) 1 GB
Flash 512 MB in total. To view the available flash memory size, run the display version command.
Mean time between failures (MTBF) 92.82 years
Mean time to repair (MTtr) 2 hours
Availability > 0.99999
Service port surge protection Common mode: ±7 kV
Power supply surge protection ±6 kV in differential mode, ±6 kV in common mode
Dimensions (H x W x D) Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Weight (with packaging) 4.08 kg (9 lb)
Stack ports Any 10/100/1000BASE-T ports or 1000BASE-X ports (applicable in V200R019C10 and later versions)
RTC Not supported
RPS Not supported
PoE Not supported
Rated voltage range AC input: 100 V AC to 240 V AC, 50/60 Hz
High-Voltage DC input: 240 V DC
Maximum voltage range AC input: 90 V AC to 264 V AC, 47 Hz to 63 Hz
High-Voltage DC input: 190 V DC to 290 V DC
Maximum power consumption (100% throughput) 34 W
Typical power consumption (30% of traffic load) 28 W
Tested according to ATIS standard
Operating temperature -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Noise under normal temperature (27°C, sound power) Noise-free (no fans)
Relative humidity 5% to 95%, noncondensing
Operating altitude 0-5000 m (0-16404 ft.)
Certification EMC certification
Safety certification
Manufacturing certification
Part number 98010926
