Description
| Item | S7710 |
| Forwarding perfomance | 2880Mpps |
| Switching capacity | 57.92/256.00T Tbps |
| Packet forwarding rate | 8400/69120Mpps |
| SRU Slot | 2 |
| Service Slot | 10 |
| Maximum port density | V100R006C00 Version: 288×FE,288×GE,72×10GE |
| V200R001C00 Version: 288×FE,288×GE,240×10GE | |
| V200R002C00~V200R007C00 Version: 288×FE,288×GE,240×10GE,12×40GE | |
| V200R008C00~V200R009C00 Version: 288×FE,288×GE,240×10GE,12×40GE,12×100~GE | |
| V200R010C00 or later version: 288×FE,288×GE,288×10GE,48×40GE,24×100GE | |
| Wireless networkmanagement | Native AC |
| AP access control, AP region management, and AP profile management | |
| Radio profile management, uniform static configuration, and centralized | |
| dynamic management | |
| Basic WLAN services, QoS, security, and user management | |
| Deployment of ACs on different network layers | |
| User management | Unified user management |
| 802.1x, MAC address, and Portal authentication | |
| Traffic- and time-based accounting | |
| User authorization based on user groups, domains, and time ranges | |
| VLAN | Three types of interfaces: access, trunk, and hybrid |
| Default VLAN | |
| VLAN switching | |
| QinQ and selective QinQ | |
| MAC address-based VLAN assignment | |
| MAC address | MAC address learning and aging. |
| Static, dynamic, and blackhole MAC address entries | |
| Packet filtering based on source MAC addresses | |
| Limit on the number of MAC addresses learned on ports and VLANs | |
| Ring Protection | STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s) |
| SEP | |
| BPDU protection, root protection, and loop protection | |
| BPDU tunnel | |
| ERPS (G.8032) | |
| IP routing | IPv4 routing protocols, such as RIPv1/v2, OSPF, BGP, and IS-IS |
| IPv6 dynamic routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+ | |
| Multicast | IGMPv1/v2/v3 and IGMP v1/v2/v3 snooping |
| PIM-DM, PIM-SM, and PIM-SSM | |
| MSDP and MBGP | |
| Fast leave | |
| Multicast traffic control | |
| Multicast querier | |
| Multicast packet suppression | |
| Multicast CAC | |
| Multicast ACL | |
| MPLS | Basic MPLS functions |
| MPLS OAM | |
| MPLS-TE | |
| MPLS VPN/VLL/VPLS | |
| Reliability | LACP and E-Trunk between devices |
| VRRP and BFD for VRRP | |
| BFD for BGP/IS-IS/OSPF/static route | |
| NSF and GR for BGP/IS-IS/OSPF/LDP | |
| TE FRR and IP FRR | |
| ITU-Y.1731 | |
| DLDP | |
| QoS | Traffic classification based on Layer 2 protocol packet header, Layer 3 protocol |
| information, Layer 4 protocol information, and 802.1p priority | |
| ACL, CAR, re-mark, and scheduling | |
| Queue scheduling algorithms including SP, WRR, DRR, SP+WRR, and SP+DRR | |
| Congestion avoidance mechanisms, such as WRED and tail drop | |
| H-QoS | |
| Traffic shaping | |
| Security and management | 802.1x authentication and portal authentication |
| NAC | |
| RADIUS and HWTACACS authentication | |
| Different user levels for commands, preventing unauthorized users from using | |
| certain command | |
| Defense against DoS attacks, TCP SYN Flood attacks, UDP Flood attacks, | |
| broadcast storms, and heavy traffic attack | |
| Ping and traceroute | |
| RMON | |
| Service Chain | |
| Interoperability | Supports VBST (Compatible with PVST/PVST+/RPVST) |
| Supports LNP (Similar to DTP) | |
| Supports VCMP (Similar to VTP) | |
| Power supply | AC:90 V to 290 V |
| Dimensions (mm) | 442 mm x 489 mm x 664 mm |
| Weight | 37 kg |
| Maximum power | 4400W |
