Description
| Product Name | SFP-GE-LX-SM1310-BIDI |
| Transmission Distance (km) | ≤ 10 |
| Standard | 1000base-BX |
| Fiber Type | Fiber mode: single-mode Connector type: LC |
| Center Wavelength (nm) | RX1490/TX1310 |
| Transmit Power (dBm) | -9.0 to -3.0 |
| Receiver Sensitivity (dBm) | ≤ -19.5 |
| Overload Optical Power (dBm) | -3.0 |
| Extinction Ratio (dB) | ≥ 6 |
| Dimension(D x W x H mm) | 130x72x35 |
Vijith –
Huawei BIDI original optical modules are very few in the market, even if they are found by chance, the price is very high
I choose to buy compatible modules at Telecomate.com, they test DDM before shipping.
