Description
| Valid Slot | ||
| OptiX OSN 8800 T32 subrack: IU1–IU8, IU12–IU27, and IU29–IU36
OptiX OSN 8800 T16 subrack: IU1–IU8, and IU11–IU18 |
||
| Feature Code | ||
| The number code that follows the board name in the bar code is the feature code of the board. The feature code of the SSN4SLQ64(S-64.2b,LC) indicates the type of optical interface. | ||
| Board | Feature Code | Type of Optical Interface |
| SSN4SLQ6402 | 02 | S-64.2b |
| Optical Interface Parameter | ||
| Parameter | Value | |
| Nominal bit rate | 9953280 kbit/s | |
| Application code | S-64.2b | |
| Transmission distance (km) | 10 to 40 | |
| Operating wavelength range (nm) | 1530 to 1565 | |
| Launched optical power range (dBm) | -1 to +2 | |
| Receiver sensitivity (dBm) | -14 | |
| Minimum overload (dBm) | -1 | |
| Minimum extinction ratio (dB) | 8.2 | |
| Mechanical Specifications | ||
| Dimensions (mm) | 25.4 (W) x 220 (D) x 266.7 (H) | |
| Weight (kg) | 1.4 | |
