Description
| Optical interface parameters | ||
| Parameter | Value | |
| Nominal bit rate | 2488320 kbit/s | |
| Line code pattern | NRZ | |
| Application code | S-16.1 | |
| Transmission distance (km) | 15 to 40 | |
| Type of fiber | Single-mode LC | |
| Operating wavelength range (nm) | 1260 to 1360 | |
| Launched optical power range(dBm) | -5 to 0 | |
| Receiver sensitivity (dBm) | -18 | |
| Minimum overload (dBm) | 0 | |
| Maximum -20 dB spectral width (nm) | 1 | |
| Minimum extinction ratio (dB) | 8.2 | |
| Minimum side mode suppression ratio (dB) | 30 | |
| Mechanical Specifications | ||
| Dimensions (mm) | 25.4 (W) x 235.2 (D) x 261.4 (H) | |
| Weight (kg) | 0.9 | |
