Description
| Feature Code | ||
| The number code that follows the board name in the bar code is the feature code of the board. The feature code of the PD1 indicates the type of interface impedance. | ||
| Board | Feature Code | Type of Interface Impedance |
| SSR2PD1A01 | A01 | 75-ohm |
| Optical Interface Parameter | ||
| The D75S, D12S, or D12B provides electrical interfaces for the PD1. For the parameters specified for the electrical interfaces, see Technical Specifications of the D12S, Technical Specifications of the D75S and Technical Specifications of the D12B. | ||
| Mechanical Specifications | ||
| Dimensions (mm) | 25.4 (W) x 220 (D) x 111.8 (H) | |
| Weight (kg) | 0.6 | |
