Description

TMF3AUX overview



Huawei OSN 9800 M12 System auxiliary Communication Board



Board Description Board Name (Silkscreen Name)
TMF3AUX01 System auxiliary Communication Board With Clock Processing Function AUX
TMF3AUX02 System auxiliary Communication Board AUX



Variants

Board

Application

TMF3AUX01

System auxiliary communication board with clock processing function.

TMF3AUX02

System auxiliary communication board without clock processing function.



Mapping relationship of the TMF3AUX board

Board

Matching Device

Matching System Control Board – Cross-Connect Board

Version of the Matching System Control and Cross-Connect Board

TMF3AUX

9800 M05

–

V100R020C10SPC300

9800 M12
  • TMF1SCC
  • TMF2SCC

V100R020C10SPC300
Show More Show Less

Functions and Features of the TMF3AUX Board (System Control and Communication Unit)

Function and Feature Description
Basic function
  • Performs service grooming and configuration management inside the subrack and reports associated alarms to the NMS.
  • The AUX board collects overheads of other boards and sends the overheads to the SCC board. Then, the SCC board processes the overheads and sends the processed overheads to the AUX board. Subsequently, the AUX board sends the processed overheads back to the other boards.
  • Supports inter-NE communication through IP over DCC or HWECC.
OTN cluster Not Supported
Master-Slave subrack Supports subrack cascading.
DCC Supports interconnection and communication between NEs through IP over DCC, or HWECC.
Backup mode Supports 1+1 hot backup. When the active board is faulty, services are automatically switched to the standby board.


Functions and Features of the TMF3AUX Board (Clock Unit)

Function and Feature Description
Basic function
  • The board provides system clock signals and frame header signals for each service board.
  • Clock synchronization: synchronizes the time of an NE to the upstream system time to complete the clock and time synchronization of the entire NE.
  • Clock source selection: The board can trace the external clock source, service clock source, or local clock source to provide the synchronization clock source for the board and the system.
NOTE:
Only the F3AUX01 board supports clock unit.
Physical clock Supported
NOTE:
Only the F3AUX01 board supports clock unit.
IEEE 1588v2 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
ITU-T G.8275.1 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
ITU-T G.8273.2 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
High-precision clock synchronization Supported
NOTE:
  • The high-precision clock synchronization function can be implemented only after the corresponding license is obtained.
  • The board must work with the subrack and system control board that supports high-precision clock to support the high-precision clock synchronization function.For details, see Clock Synchronization Feature Guide.
  • Only the F3AUX01 board supports the high-precision clock synchronization function.
ITU-T G.8271 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
Backup mode Supports 1+1 hot backup.


Functions and Features of the TMF3AUX Board (Interface Unit)

Function and Feature Description
Interface
  • Provides common and emergency inter-subrack communication interfaces.
  • Provides clock and time signal input and output interface.


Mechanical Specifications

Board Item Unit Value
TMF3AUX02 Dimensions (H x W x D) mm 176.00×20.30×267.35
Dimensions (H x W x D) in. 6.93×0.80×10.53
Weight kg 0.9
Weight lb. 1.98
Typical Power Consumption W 33
Maximum Power Consumption W 37
TMF3AUX01 Dimensions (H x W x D) mm 176.00×20.30×267.35
Dimensions (H x W x D) in. 6.93×0.80×10.53
Weight kg 0.9
Weight lb. 1.98
Typical Power Consumption W 37
Maximum Power Consumption W 42

Additional information

Brand

Huawei
Lead Time

3-5 days
Ship From

Shenzhen Warehouse

Functions and Features of the TMF3AUX Board (System Control and Communication Unit)

Function and Feature Description
Basic function
  • Performs service grooming and configuration management inside the subrack and reports associated alarms to the NMS.
  • The AUX board collects overheads of other boards and sends the overheads to the SCC board. Then, the SCC board processes the overheads and sends the processed overheads to the AUX board. Subsequently, the AUX board sends the processed overheads back to the other boards.
  • Supports inter-NE communication through IP over DCC or HWECC.
OTN cluster Not Supported
Master-Slave subrack Supports subrack cascading.
DCC Supports interconnection and communication between NEs through IP over DCC, or HWECC.
Backup mode Supports 1+1 hot backup. When the active board is faulty, services are automatically switched to the standby board.


Functions and Features of the TMF3AUX Board (Clock Unit)

Function and Feature Description
Basic function
  • The board provides system clock signals and frame header signals for each service board.
  • Clock synchronization: synchronizes the time of an NE to the upstream system time to complete the clock and time synchronization of the entire NE.
  • Clock source selection: The board can trace the external clock source, service clock source, or local clock source to provide the synchronization clock source for the board and the system.
NOTE:
Only the F3AUX01 board supports clock unit.
Physical clock Supported
NOTE:
Only the F3AUX01 board supports clock unit.
IEEE 1588v2 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
ITU-T G.8275.1 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
ITU-T G.8273.2 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
High-precision clock synchronization Supported
NOTE:
  • The high-precision clock synchronization function can be implemented only after the corresponding license is obtained.
  • The board must work with the subrack and system control board that supports high-precision clock to support the high-precision clock synchronization function.For details, see Clock Synchronization Feature Guide.
  • Only the F3AUX01 board supports the high-precision clock synchronization function.
ITU-T G.8271 Supported
NOTE:
Only the F3AUX01 board supports clock unit.
Backup mode Supports 1+1 hot backup.


Functions and Features of the TMF3AUX Board (Interface Unit)

Function and Feature Description
Interface
  • Provides common and emergency inter-subrack communication interfaces.
  • Provides clock and time signal input and output interface.


Mechanical Specifications

Board Item Unit Value
TMF3AUX02 Dimensions (H x W x D) mm 176.00×20.30×267.35
Dimensions (H x W x D) in. 6.93×0.80×10.53
Weight kg 0.9
Weight lb. 1.98
Typical Power Consumption W 33
Maximum Power Consumption W 37
TMF3AUX01 Dimensions (H x W x D) mm 176.00×20.30×267.35
Dimensions (H x W x D) in. 6.93×0.80×10.53
Weight kg 0.9
Weight lb. 1.98
Typical Power Consumption W 37
Maximum Power Consumption W 42
