Huawei OptiX OSN 9800 TNG1DMSE 32 x E1 Electrical Interface Board

Description

TNG1DMSE overview



TNG1DMSE 32 x E1 Electrical Interface Board applied to Huawei OptiX OSN 9800 IU1, IU12, IU13, IU24.

To meet ultra-large cross-connect capacity and bandwidth requirements, Huawei presents the OptiX OSN 9800 product series. The OptiX OSN 9800 product series include the OptiX OSN 9800 U64, U32, P18 and universal platform subracks. Applied at the electrical layer, the OptiX OSN 9800 U64 and U32 subracks share boards by using unified software and hardware platforms, and can work with the OptiX OSN 9800 universal platform subrack and P18 subrack, OptiX OSN 8800 platform subrack and T16 subrack, and OptiX OSN 6800 optical subracks in WDM and OTN systems.

The TNG1DMSE board has only one variant, that is, TNG1DMSE.



Front panel of the TNG1DMSE board

TNG1DMSE

Front panel of the TNG1DMSE board



Valid slots for the TNG1DMSE board in a IU1, IU12, IU13, IU24 subrack

Product Valid Slots
OptiX OSN 9800 M24 subrack IU1, IU12, IU13, IU24



Product Logical slots for the PD1 (primary, secondary) Slot Valid for the DMSE
OptiX OSN 9800 M24 subrack 142, 190 IU1
153, 201 IU12
154, 202 IU13
159, 207 IU24
Item TNG1DMSE
Basic function Provides input and output ports of signal cables for the PD1 board.
Port specifications Supports thirty-two 75 Ω/120 Ω E1 ports.
TPS Works together with two PD1 boards to implement TPS protection.
Tributary clock sources Supports source selection for E1 clocks.
Alarm and performance event monitoring Monitors the operating temperature of the board and reports alarms.

Additional information

Item TNG1DMSE
Basic function Provides input and output ports of signal cables for the PD1 board.
Port specifications Supports thirty-two 75 Ω/120 Ω E1 ports.
TPS Works together with two PD1 boards to implement TPS protection.
Tributary clock sources Supports source selection for E1 clocks.
Alarm and performance event monitoring Monitors the operating temperature of the board and reports alarms.
