V173-50Hot

0 Reviews Write a review
SKU2025924
Brands
AvailabilityIn Stock
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Huawei OptiXstar V173-50 supports 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

Huawei OptiXstar V173-50 supports 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi, is the main FTTR of Huawei FTTR All-Optical Home Starlight F30 Premium Edition, which realizes ultra-broadband access for users through GPON or XG-PON technology.



Product Features

Item Discribtion
Smart connectivity
  • Wi-Fi Smart Coverage
  • SIP/H.248 Adaptive
  • Any port Any service
  • Parental Controls
Intelligent Operation and Maintenance
  • IPTV video quality diagnosis
  • OLT-initiated rogue ONT detection and isolation
  • WLAN Emulation
  • PPPOE/DHCP emulation test
Multicast
  • IGMP v2/v3 snooping
  • IGMP v2/v3 proxy
  • MLD v1/v2 snooping
Layer 3 Features
  • PPPoE/Static IP/DHCP
  • NAT/NAPT
  • Port forwarding
  • ALG,UPnP
  • DDNS/DNS server/DNS Client
  • IPv6/IPv4 dual stack, DS-Lite
  • Static routing/default routing
  • One WAN carries multiple services
Safety
  • SPI Firewall
  • Anti-DOS attack
  • MAC/IP/URL address filtering
O&M
  • OMCI/Web UI/TR069
  • Variable length OMC
  • Software dual backup and rollback
QoS
  • Ethernet port speed limit
  • 802.1p Priority
  • SP/WRR/SP+WRR
  • Broadcast message rate limit
Energy saving
  • Indicator light energy saving control
  • TWT Energy Saving
Home Network
  • Fiber to the room, realizing all-optical home networking
  • C-WAN architecture, centralized control and resource coordination of the entire Wi-Fi network through the main FTTR
  • Wi-Fi dedicated channel intelligent acceleration
  • Smart Wi-Fi optimization in your home network
  • Seamless Wi-Fi roaming within the home network (SRCN roaming technology, compatible with 802.11k/802.11v 2)
Home Network Management(With NCE support)
  • Visual management of home network
  • Remote management and maintenance
  • Installation and Maintenance Assistant APP 3 Management
  • User mobile phone APP 3 management: Installation Instructions/Home network topology visualization/Wi-Fi Configuration/Wi-Fi Timer Switch/Blacklist, Parental Control/One-click network optimization/One-click detection and remote repair
Show More Show Less

Hardware specifications

Item Specifications
Power supply: 12V DC, 2 A，
Working environment temperature: 0°C ~ +40°C，
Working environment humidity: 5% RH to 95% RH (non-condensing)
Power adapter rated input Range: 170 ~ 240 V AC, 50/60 Hz
Maximum power consumption: 24 W
Network side interface: GPON/XG-PON
User side interface: 4GE+1*POTS+1*USB2.0+1*下行 光口+2.4GHz&5GHz Wi-Fi
Optical connector: Network side: SC/UPC User side: SC/UPC
Indicator Lights Front indicator light Back indicator light: Registration/optical signal/telephone/USB/wireless/WPS/downlink optical/network port Indicator light
Storage: 256MB Flash，512MB RAM
Installation Scenario： Desktop stand
Dimensions (H x W x D): 157mm x 250mm x 30mm (Without base)
Weight (excluding adapter) Approximately: 600 g


Interface parameters

Type Parameters
XG-PON/GPON
  • XG-PON：Class N1/N2a
  • GPON：Class B+
  • Receiver sensitivity:XG-PON：-28dBm; GPON：-27dBm
  • Wavelength: XG-PON: Upstream 1270nm, Downstream 1577nm; GPON: Upstream 1310nm, Downstream 1490nm
  • Support band-stop filter (WBF)
  • Flexible mapping between GEM Port and TCONT
  • Authentication: SN/Password/SN + Password/bidirectional authentication based on OMCI (XG-PON); Password/LOID/SN(GPON)
  • Bidirectional FEC(Forward Error Correction)
  • Support SR, NSR DBA
  • Uplink and downlink rates: Uplink and downlink speeds: Uplink 2.488Gbit/s, downlink 9.953Gbit/s (XG-PON); Uplink 1.25Gbit/s, downlink 2.488Gbit/s (GPON)
USB port
  • USB 2.0
Wi-Fi
  • IEEE 802.11 b/g/n/ax(2.4GHz)
  • IEEE 802.11 a/n/ac/ax(5GHz)
  • 2×2 MIMO（2.4GHz&5GHz）
  • WMM(Wi-Fi Multi Media)
  • 1024 QAM
  • 160MHz bandwidth
  • WPA3/WPA2/WPA1
  • Multi-SSID
  • WPS
  • MU-MIMO
  • Air interface rate: 574 Mbps (2.4GHz)，2402
Network port 1~4
  • VLAN Tag/Tag stripping based on Ethernet port
  • 1:1 VLAN/N:1 VLAN/VLAN pass-through
  • QinQ VLAN
  • Limit on the number of learned MAC addresses
  • MAC address learning
  • Support 10/100/1000Mbps adaptive
Downstream optical interface
  • P2MP Optical Interface
  • From FTTR Plug and Play
POTS port
  • Maximum ringer equivalence number (REN): 4
  • G.711A/u, G.729a/b, G.722 encoding/decoding
  • T.30/T.38/G.711 fax mode
  • DTMF
  • Emergency calls (with the SIP protocol)

Additional information

Brand

Huawei

Hardware specifications

Item Specifications
Power supply: 12V DC, 2 A，
Working environment temperature: 0°C ~ +40°C，
Working environment humidity: 5% RH to 95% RH (non-condensing)
Power adapter rated input Range: 170 ~ 240 V AC, 50/60 Hz
Maximum power consumption: 24 W
Network side interface: GPON/XG-PON
User side interface: 4GE+1*POTS+1*USB2.0+1*下行 光口+2.4GHz&5GHz Wi-Fi
Optical connector: Network side: SC/UPC User side: SC/UPC
Indicator Lights Front indicator light Back indicator light: Registration/optical signal/telephone/USB/wireless/WPS/downlink optical/network port Indicator light
Storage: 256MB Flash，512MB RAM
Installation Scenario： Desktop stand
Dimensions (H x W x D): 157mm x 250mm x 30mm (Without base)
Weight (excluding adapter) Approximately: 600 g


Interface parameters

Type Parameters
XG-PON/GPON
  • XG-PON：Class N1/N2a
  • GPON：Class B+
  • Receiver sensitivity:XG-PON：-28dBm; GPON：-27dBm
  • Wavelength: XG-PON: Upstream 1270nm, Downstream 1577nm; GPON: Upstream 1310nm, Downstream 1490nm
  • Support band-stop filter (WBF)
  • Flexible mapping between GEM Port and TCONT
  • Authentication: SN/Password/SN + Password/bidirectional authentication based on OMCI (XG-PON); Password/LOID/SN(GPON)
  • Bidirectional FEC(Forward Error Correction)
  • Support SR, NSR DBA
  • Uplink and downlink rates: Uplink and downlink speeds: Uplink 2.488Gbit/s, downlink 9.953Gbit/s (XG-PON); Uplink 1.25Gbit/s, downlink 2.488Gbit/s (GPON)
USB port
  • USB 2.0
Wi-Fi
  • IEEE 802.11 b/g/n/ax(2.4GHz)
  • IEEE 802.11 a/n/ac/ax(5GHz)
  • 2×2 MIMO（2.4GHz&5GHz）
  • WMM(Wi-Fi Multi Media)
  • 1024 QAM
  • 160MHz bandwidth
  • WPA3/WPA2/WPA1
  • Multi-SSID
  • WPS
  • MU-MIMO
  • Air interface rate: 574 Mbps (2.4GHz)，2402
Network port 1~4
  • VLAN Tag/Tag stripping based on Ethernet port
  • 1:1 VLAN/N:1 VLAN/VLAN pass-through
  • QinQ VLAN
  • Limit on the number of learned MAC addresses
  • MAC address learning
  • Support 10/100/1000Mbps adaptive
Downstream optical interface
  • P2MP Optical Interface
  • From FTTR Plug and Play
POTS port
  • Maximum ringer equivalence number (REN): 4
  • G.711A/u, G.729a/b, G.722 encoding/decoding
  • T.30/T.38/G.711 fax mode
  • DTMF
  • Emergency calls (with the SIP protocol)
