V173Hot

2 Reviews Write a review
SKU2025905
Brands
AvailabilityIn Stock
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Huawei OptiXstar V173 support 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi

    Tech Support
    Service Commitment
    Steps Shipping
    Customer Satisfacition

Description

Huawei OptiXstar V173 support 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi, is the main FTTR of Huawei FTTR All-Optical Home Starlight F30 Premium Edition, which realizes ultra-broadband access for users through XG-PON or asymmetric 10G EPON technology.

Hardware specifications

Item Specifications
Power supply: 12V DC, 2 A，
Working environment temperature: 0°C ~ +40°C，
Working environment humidity: 5% RH to 95% RH (non-condensing)
Power adapter rated input Range: 170 ~ 240 V AC, 50/60 Hz
Maximum power consumption: 20 W
Network side interface: XG-PON/Asymmetric 10G-EPON
User side interface: 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi
Optical connector: Network side: SC/UPC User side: SC/UPC
Indicator Lights Front indicator light Back indicator light: Registration/optical signal/telephone/USB/wireless/WPS/downlink optical/network port Indicator light
Storage: 256MB Flash，512MB RAM
Installation Scenario： Desktop stand
Dimensions (H x W x D): 157mm x 250mm x 30mm (Without base)
Weight (excluding adapter) Approximately: 600 g


Interface parameters

Type Parameters
XG-PON/Asymmetric 10G EPON
  • XG-PON：Class N1/N2a
  • Asymmetric 10G EPON: Class PRX 30
  • Receiver sensitivity:XG-PON: -28dBm; Asymmetric 10G EPON: -28.5dBm
  • Wavelength: Upstream 1260-1280nm; Downstream 1575-1580nm (XG-PON/Asymmetric 10G EPON)
  • Support band-stop filter (WBF)
  • Authentication: SN/Password/SN + Password/bidirectional authentication based on OMCI (XG-PON); MAC/Key/LOID(asymmetric 10G EPON)
  • Bidirectional FEC(Forward Error Correction)
  • Support SR, NSR DBA
  • Uplink and downlink rates: Upstream 2.488Gbit/s, downstream 9.953Gbit/s (XG-PON); Upstream 1.25Gbit/s, downstream 10.3125Gbit/s (asymmetric 10G EPON)
USB port
  • USB 2.0
Wi-Fi
  • IEEE 802.11 b/g/n/ax(2.4GHz)
  • IEEE 802.11 a/n/ac/ax(5GHz)
  • 2×2 MIMO（2.4GHz&5GHz）
  • WMM(Wi-Fi Multi Media)
  • 1024 QAM
  • 160MHz bandwidth
  • WPA3/WPA2/WPA1
  • Multi-SSID
  • WPS
  • MU-MIMO
  • Air interface rate: 574 Mbps (2.4GHz)，2402 Mbps (5GHz)
Network port 1~4
  • VLAN Tag/Tag stripping based on Ethernet port
  • 1:1 VLAN/N:1 VLAN/VLAN pass-through
  • QinQ VLAN
  • Limit on the number of learned MAC addresses
  • MAC address learning
  • Support 10/100/1000Mbps adaptive
Downstream optical interface
  • P2MP Optical Interface
  • From FTTR Plug and Play
POTS port
  • Maximum ringer equivalence number (REN): 4
  • G.711A/u, G.729a/b, G.722 encoding/decoding
  • T.30/T.38/G.711 fax mode
  • DTMF
  • Emergency calls (with the SIP protocol)

Additional information

Brand

Huawei

Hardware specifications

Item Specifications
Power supply: 12V DC, 2 A，
Working environment temperature: 0°C ~ +40°C，
Working environment humidity: 5% RH to 95% RH (non-condensing)
Power adapter rated input Range: 170 ~ 240 V AC, 50/60 Hz
Maximum power consumption: 20 W
Network side interface: XG-PON/Asymmetric 10G-EPON
User side interface: 4GE+1*POTS+1*USB2.0+1*downlink Optical port+2.4GHz&5GHz Wi-Fi
Optical connector: Network side: SC/UPC User side: SC/UPC
Indicator Lights Front indicator light Back indicator light: Registration/optical signal/telephone/USB/wireless/WPS/downlink optical/network port Indicator light
Storage: 256MB Flash，512MB RAM
Installation Scenario： Desktop stand
Dimensions (H x W x D): 157mm x 250mm x 30mm (Without base)
Weight (excluding adapter) Approximately: 600 g


Interface parameters

Type Parameters
XG-PON/Asymmetric 10G EPON
  • XG-PON：Class N1/N2a
  • Asymmetric 10G EPON: Class PRX 30
  • Receiver sensitivity:XG-PON: -28dBm; Asymmetric 10G EPON: -28.5dBm
  • Wavelength: Upstream 1260-1280nm; Downstream 1575-1580nm (XG-PON/Asymmetric 10G EPON)
  • Support band-stop filter (WBF)
  • Authentication: SN/Password/SN + Password/bidirectional authentication based on OMCI (XG-PON); MAC/Key/LOID(asymmetric 10G EPON)
  • Bidirectional FEC(Forward Error Correction)
  • Support SR, NSR DBA
  • Uplink and downlink rates: Upstream 2.488Gbit/s, downstream 9.953Gbit/s (XG-PON); Upstream 1.25Gbit/s, downstream 10.3125Gbit/s (asymmetric 10G EPON)
USB port
  • USB 2.0
Wi-Fi
  • IEEE 802.11 b/g/n/ax(2.4GHz)
  • IEEE 802.11 a/n/ac/ax(5GHz)
  • 2×2 MIMO（2.4GHz&5GHz）
  • WMM(Wi-Fi Multi Media)
  • 1024 QAM
  • 160MHz bandwidth
  • WPA3/WPA2/WPA1
  • Multi-SSID
  • WPS
  • MU-MIMO
  • Air interface rate: 574 Mbps (2.4GHz)，2402 Mbps (5GHz)
Network port 1~4
  • VLAN Tag/Tag stripping based on Ethernet port
  • 1:1 VLAN/N:1 VLAN/VLAN pass-through
  • QinQ VLAN
  • Limit on the number of learned MAC addresses
  • MAC address learning
  • Support 10/100/1000Mbps adaptive
Downstream optical interface
  • P2MP Optical Interface
  • From FTTR Plug and Play
POTS port
  • Maximum ringer equivalence number (REN): 4
  • G.711A/u, G.729a/b, G.722 encoding/decoding
  • T.30/T.38/G.711 fax mode
  • DTMF
  • Emergency calls (with the SIP protocol)
