XMI20HR

0 Reviews Write a review
AvailabilityIn Stock
WarrantyUp to 36 months i
×
Warranty Policy
We provide a comprehensive warranty policy.
Refer to the table for more details.

Aveda XMI20HR Inverter 2000VA/1600W. 2KVA.

Description

XMI20HR overview



Application Field
Telecommunication base stations, network optimization, railway, post, public security, and other special network computer room systems.

Performance Characteristics
Unique anti-injection noise suppression technology
1. Unique pre-filter design, eliminates the impact, surge, sinking, and noise interference to the power grid.

N+X redundant parallel technology
1. High reliability the system does not require any additional parallel cabinet: parallel operation is realized by the internal microprocessor.
2. Adopts non-master-slave current sharing mode with high-precision load sharing.

Intelligent monitoring interface
1. With RS485/RS232 interface or optional SNMP for remote monitoring.

Direct use of the original DC system
1. Save system investment and reduce maintenance costs and can be well matched with cascade batteries.

Online design
1. Relay + SCR compensation: inverter functional switching will never cause load flicker Realize long-term backup of load equipment.

AC and DC dual-loop input design structure
1.No need to increase the capacity of the rectifier and provide full protection for critical load.

Model XMI20HR
Capacity 2kVA
AC Voltage Single phase220VAC/176-250VAC(settable)
Frequency 50Hz±5%
DC Voltage 48VDC
Relative Wideband Noise Current Back-sinking at the Input <10%
Measurement Of Noise Current Relative To Telephone By Input Feedback <2‰
Output Voltage Single phase 220VAC
Efficiency (Inverter Mode) >90%
Power Factor 0.8
Communication Interface RS485/RS232、dry contact
SNMP Optional

Additional information

Model XMI20HR
Capacity 2kVA
AC Voltage Single phase220VAC/176-250VAC(settable)
Frequency 50Hz±5%
DC Voltage 48VDC
Relative Wideband Noise Current Back-sinking at the Input <10%
Measurement Of Noise Current Relative To Telephone By Input Feedback <2‰
Output Voltage Single phase 220VAC
Efficiency (Inverter Mode) >90%
Power Factor 0.8
Communication Interface RS485/RS232、dry contact
SNMP Optional
