CR5D00C4CFC1

CR5D00C4CFC1

NE8000 CR5D00C4CFC1(4*Port Channelized STM-1c POS-SFP Physical Interface Card(PIC))

Huawei

3-5 days

Shenzhen Warehouse

SKU: 2009831 PN: 03033GGF Category:

Description

Basic information about the CR5D00C4CFC1

Item Details
Description 4-Port Channelized STM-1c POS-SFP Physical Interface Card(PIC)
Card type Interface Card
Part Number 03033GGF
Model CR5D00C4CFC1
Silkscreen 4xSTM1-cPOS



Mappings between CR5D00C4CFC1 and product models

Product Sub-Series
Product Model
First Supported Version
Limitations
NetEngine 8000 M14 CR8B0BKPACC2 NetEngine 8000 M V800R012C00
NetEngine 8000 M14 CR8B0BKPDCC1 NetEngine 8000 M V800R012C00
NetEngine 8000 M14 CR8B0BKPACC1 NetEngine 8000 M V800R012C10
NetEngine 8000 M8 CR8BM8BKPDC1 NetEngine 8000 M V800R012C00
NetEngine 8000 M8 CR8BM8BKPAC1 NetEngine 8000 M V800R012C00



Item CR5D00C4CFC1
Basic function Supports 63 E1 links over four 155M SDH links.
Reliability and availability Supports the hot swappable function.
Breakout supported No
Interface rate auto-sensing supported No
Link protocol TDM, PPP, MP, ATM, IMA
Dimensions without packaging (H x W x D) [mm(in.)] 19.8 mm x 193.8 mm x 209.3 mm (0.78 in. x 7.63 in. x 8.24 in.)
Weight without packaging [kg(lb)] 0.5 kg (1.1 lb)
Typical power consumption [W] 16.8 W
Typical heat dissipation [BTU/hour] 54.5 BTU/hour
Long-term operating temperature [°C(°F)] -20°C to 65°C(-4°F to 149°F)
