EH1D2SRUC000

PN 03021UWG

S9706/S9712 Main Control Unit C(Optional Clock)

Shenzhen Warehouse
lead time 3-5 days
- +
Overview
Item EH1D2SRUC000
Apply to S9700 series
Attribute of a ETH management port
Connector type RJ45
Standards compliance IEEE802.3

Working mode

10/100 Mbit/s auto-sensing

Full-duplex

Maximum transmission distance 100m
Attribute of a console manangement port
Connector type RJ45
Working mode Duplex Universal Asynchronous Receiver/Transmitter (UART)
Standards compliance RS232
Baud rate

9600 bit/s to 115200 bit/s

Default value: 9600 bit/s

Attribute of BITS port
Connector type RJ45
Working mode

Clock synchronization mode: full-duplex

Time synchronization mode: half-duplex

Frame format

1 pps + Time of Day (ToD)

DC Level Shifter (DCLS)

2 MHz

2 Mbit/s: HDB3 code

1.544 Mbit/s: B8ZS code

Standards compliance

1 pps + ToD

NMEA-0183

ToD standard of China Mobile

DCLS: standard of DCLS signals

2 MHz: G.703

2 Mbit/s: G.703

1.544 Mbit/s: G.703

Cable used

Time synchronization mode: straight through network cable (RS422 signal)

Clock synchronization mode: E1/T1 cable (120-ohm balanced cable)

Attribute of USB port
Connector type USB A
Standards compliance USB2.0
Physical specification
Dimensions (mm) 394.7 mm x 426.8 mm x 35.1 mm (5.7 in. x 7.3 in. x 0.8 in.)
Weight (kg) 3.30 kg (7.28 lb)
Maximum power consumption 132 W
Environment parameters
Operating temperature 0°C to 45°C (32°F to 113°F)
Operating relative humidity 5% RH to 95% RH (noncondensing)
Storage temperature -40°C to +70°C (-40°F to +158°F)
Storage relative humidity 5% RH to 95% RH (noncondensing)
