PRODUCT OVERVIEW & MARKET POSITIONING
The modern enterprise campus network demands a core switching platform that simultaneously delivers carrier-grade reliability, wire-speed performance, and future-ready scalability. The [MODEL_CORE_SWITCH] series has been architected to serve as the unified fabric for high-density campus environments, consolidating Gigabit-to-100G Ethernet access layers, security services, and network virtualization overlays without compromise.
ARCHITECTURE & CHASSIS DESIGN
Based on a non-blocking Clos switching fabric, the [MODEL_CORE_SWITCH] deploys a distributed forwarding architecture with hardware-based VXLAN routing and inline encryption offload. The modular chassis supports hot-swappable supervisor engines, line cards, power supplies, and fan trays—all accessible from the front or rear (reversible airflow option). Key design pillars include:
– 4.8 Tbps to 25.6 Tbps switching capacity (depending on line card population)
– Sub-microsecond port-to-port latency for all frame sizes
– Hardware-assisted In-Service Software Upgrade (ISSU) with zero packet loss
– Support for 400 GbE downlink/uplink optical interfaces
HARDWARE FEATURES & PERFORMANCE CAPABILITIES
The switching engine integrates a programmable pipeline ASIC supporting P4 language extensions. Feature highlights:
– MAC address table: 512K entries
– IPv4/IPv6 route table (FIB): 1M routes
– ACL rules: 32K ingress + 16K egress
– Jumbo frame support up to 12K bytes
– 1+1 route processor redundancy with sub-100 ms failover
– N+1 fabric module redundancy for fully distributed forwarding
TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Form Factor | 5-slot or 8-slot modular chassis, 7RU/13RU respectively |
| Switching Capacity | 4.8 Tbps (5-slot) to 25.6 Tbps (8-slot, fully loaded) |
| Forwarding Rate | 3.6 Bpps to 19.2 Bpps (64-byte packets) |
| Power Supply | 1+1 or 2+2 redundant, AC (3000W) or DC (2400W) |
| Operating Temperature | 0°C to 45°C (long term), -5°C to 55°C (short term) |
| Humidity | 5% to 95% non-condensing |
| MTBF | >300,000 hours (Telcordia SR-332, 40°C) |
| Management Interfaces | 1x RJ45 console, 1x USB-C console, 1x 10/100/1000 MGMT, 1x 1G SFP MGMT |
| Layer 3 Features | OSPF, BGP, IS-IS, VRRP, PIM-SM, VXLAN EVPN, SR-MPLS |
| Security | MACsec 256 (line-rate on all ports), hardware ACL, CPU rate-limiting |
COMPLIANCE & STANDARDS
The platform satisfies comprehensive industry regulatory and interoperability mandates:
– IEEE 802.1Q, 802.1ad, 802.1Qbu/802.3br (TSN)
– ITU-T G.8032 Ethernet Ring Protection
– MEF 42 (Carrier Ethernet 2.0)
– Energy Efficient Ethernet (IEEE 802.3az)
– RoHS, REACH, WEEE compliance
– NEBS Level 3 (GR-63-CORE, GR-1089-CORE)
– EMC: FCC Part 15 Class A, EN 55032 Class A, CISPR 32
– Safety: UL 62368-1, IEC 62368-1, EN 62368-1
ORDERING OPTIONS & SKU GUIDE
– [MODEL_CORE_SWITCH]-8SLOT – 8-slot modular chassis (includes fabric module slots)
– [MODEL_CORE_SWITCH]-5SLOT – 5-slot modular chassis
– SUP-[YEAR] – Supervisor engine module with 64GB DRAM, 64GB eMMC
– LINE-CARD-48x25G-SFP – 48x25G SFP28 + 8x100G QSFP28 line card
– LINE-CARD-32x100G-QSFP28 – 32x100G QSFP28 line card
– PWR-AC-3000W – 3000W AC power supply, 1+1/2+2 redundancy
– PWR-DC-2400W – -48V DC power supply, 1+1 redundancy
– FAN-TRAY-REV – Reversible airflow fan tray kit
DEPLOYMENT TOPOLOGY EXAMPLE
Typical deployment: Two [MODEL_CORE_SWITCH] units in a Virtual Port Channel (vPC) / StackWise Virtual configuration, each connecting to distribution switches (10G/25G uplinks) and downstream access switches (1G/10G). Core links operate at 40G/100G to aggregation routers and firewall clusters. L2/L3 gateway services, VXLAN EVPN multi-tenancy, and MACsec on all inter-switch links complete the architecture.
LIFECYCLE ASSURANCE & SUPPORT
– MTBF (Mean Time Between Failures): >300,000 hours (Telcordia SR-332, 40°C)
– MTTR (Mean Time To Repair):
