Huawei H801GICF 2-port GE optical uplink board without SFP module, apply to Huawei MA5680T/MA5683T
The H801GICF board is a 2-port GE optical uplink board, which can be used in the Huawei MA5600T series OLTs: MA5683T MA5680T.
This board comes without any optical transceivers, it is supposed to work with two GE 10km SFP modules.
| Item | H801GICF |
| Port | 2 GE Optical Uplink Ports |
| Pluggable Module | Optical Module(SFP) Electrical Module(SFP) |
| Corresponding Control Board | SCUN/SCUL/SCUH |
| SFP Module specification | |
| SFP module type (typical configuration) | One-channel two-fiber bi-directional optical module |
| Operating Wavelength | 1310 nm |
| Encapsulation Type | SFP |
| Port Rate | 1.25 Gbit/s |
| Minimum Output Optical Power | -9.00 dBm/-9.50 dBm |
| Maximum Output Optical Power | -3.00 dBm |
| Maximum Receiver Sensitivity | -20.00dBm |
| Optical Connector Type | LC |
| Optical Fiber Type | Single-mode |
| Reach | 10.00KM |
| Overload Optical Power | -3.0 dBm |
| Extinction Ratio | 9.0 dB |
| Device Specifications | |
| Dimensions (mm) | 25.40 (W) x 237.00 (D) x 197.20 (H) |
| Power Consumption and Maximum Frame Size | |
| Power Consumption | H801GICF : Static: 3.9 W Maximum: 3.9 W |
| Maximum Frame Size | 2052 bytes. After jumbo frame function is enabled, a maximum of 9216 bytes can be supported. |
| Operating temperature | -25°C to +65°C |
| Relation between GE optical/electrical modules and boards | One-channel Two-fiber Bi-directional GE Optical Module |
| One-channel One-fiber Bi-directional GE Optical Module | |
| One-channel Two-fiber Bi-directional GE CWDM Optical Module | |
| GE Electrical Module | |
| Weight | 2.5000 kg |
|---|---|
| Dimensions | 34.0000 × 25.5000 × 10.0000 cm |
| Brand | Huawei |
| Lead Time | 3-5 days |
| Ship From | Shenzhen Warehouse |
| MA5600T |
| Item | H801GICF |
| Port | 2 GE Optical Uplink Ports |
| Pluggable Module | Optical Module(SFP) Electrical Module(SFP) |
| Corresponding Control Board | SCUN/SCUL/SCUH |
| SFP Module specification | |
| SFP module type (typical configuration) | One-channel two-fiber bi-directional optical module |
| Operating Wavelength | 1310 nm |
| Encapsulation Type | SFP |
| Port Rate | 1.25 Gbit/s |
| Minimum Output Optical Power | -9.00 dBm/-9.50 dBm |
| Maximum Output Optical Power | -3.00 dBm |
| Maximum Receiver Sensitivity | -20.00dBm |
| Optical Connector Type | LC |
| Optical Fiber Type | Single-mode |
| Reach | 10.00KM |
| Overload Optical Power | -3.0 dBm |
| Extinction Ratio | 9.0 dB |
| Device Specifications | |
| Dimensions (mm) | 25.40 (W) x 237.00 (D) x 197.20 (H) |
| Power Consumption and Maximum Frame Size | |
| Power Consumption | H801GICF : Static: 3.9 W Maximum: 3.9 W |
| Maximum Frame Size | 2052 bytes. After jumbo frame function is enabled, a maximum of 9216 bytes can be supported. |
| Operating temperature | -25°C to +65°C |
| Relation between GE optical/electrical modules and boards | One-channel Two-fiber Bi-directional GE Optical Module |
| One-channel One-fiber Bi-directional GE Optical Module | |
| One-channel Two-fiber Bi-directional GE CWDM Optical Module | |
| GE Electrical Module | |
