Description
Huawei MA5616 main control board integrated with 2-port GE/GPON adaptive optical ports
| Specification | |
| Support GPON uplink ports | UP2A: Two adaptive optical ports UP2C: Two adaptive optical ports XP1A: One 10G GPON optical port TP2C: One 10G EPON optical port |
| Supported Daughter Board | Upstream daughter board: UP2A/UP2C/XP1A |
| Voice daughter board: ASDA/ADSC/ASDM | |
| Port on the Front Panel (on the Bottom Plate) | CON/ESC/ETH/CLK/TOD/ALARM /GE |
| Upstream Port (on the Daughter Board) | When the UP2A or UP2C daughter board is configured: 0 (SFP port)/ 1 (SFP port) |
| When the XP1A daughter board is configured: 10G GPON (SFP port) | |
| Operating temperature | -40℃ to 65℃; startup at -25℃ |
| Humidity | 5% to 95% (non-condensing) |
| Power supply | AC: 220 V/110 V, DC: -48 V |
| Clock features | Network time synchronization |
| Line clocks recovered on upstream ports | |
| Mechanical Specification | |
| Dimensions (H×W×D) | CCUC:140 mm x 220 mm x 40.14 mm |
Brazel Trevino –
CCUC Supports 2-port GE/GPON adaptive optical ports. The products are beautiful and the seller is wonderful. I placed multiple orders to my customers and they made sure to get everything shipped out very quickly. I am so pleased with my purchase! These will be a wonderful order! Thank you so much!
Marlow –
This is the second purchase, as always, a good shopping experience.
