Huawei AR6710-L8T3TS1X2 Best Price At Telecomate.com

Huawei AR6710-L8T3TS1X2

0 out of 5

0 customer reviews|Add a review

Huawei AR6710-L8T3TS1X2 support 2*GE combo WAN, 1*10GE(SFP+) WAN, 8*GE LAN, 1*GE combo LAN, 2*USB 2.0, 2*SIC

Brand: Huawei

Lead Time: 3-5 days

Ship From: Shenzhen Warehouse

SKU: 2013849 Category: AR Series

Description
DATASHEET
Reviews (0)

Description

Overview

AR6710-L8T3TS1X2, 2*GE combo WAN, 1*10GE(SFP+) WAN, 8*GE LAN, 1*GE combo LAN, 2*USB 2.0, 2*SIC

Item	Details
Description	2GE combo WAN, 110GE(SFP+) WAN, 8GE LAN, 1GE combo LAN, 2USB 2.0, 2SIC
Part Number	02354PUH
Model	AR6710-L8T3TS1X2
First supported version	V600R022C00

Item	AR6710-L8T3TS1X2
Installation type	Rack Work bench Against the wall
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 220.4 mm (1.75 in. x 17.41 in. x 8.68 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 225.2 mm (1.75 in. x 17.41 in. x 8.87 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	390 mm x 570 mm x 390 mm (15.35 in. x 22.44 in. x 15.35 in.)
Chassis height [U]	1 U
Weight with packaging [kg(lb)]	4.6 kg (10.12 lb)
Weight without packaging [kg(lb)]	3.2 kg (7.04 lb)
CPU	1.4 GHz, quad-core
Memory	4 GB
NAND Flash	2 GB
Console port	RJ45
RTC	Supported
Maximum power consumption [W]	33 W
Power supply mode	Built-in AC
Number of power modules	1
Rated input voltage [V]	100 V to 240 V, 50 Hz/60 Hz
Input voltage range [V]	90 V to 264 V, 47 Hz to 63 Hz
Maximum input current [A]	2 A
Maximum output power [W]	70 W
Type of fans	Built-in fans
Number of fan modules	1
Heat dissipation mode	Air cooling
Airflow direction	Left to right
Extended slots (standard configuration)	2 x SIC
Number of service board slots	2
Redundant power supply	Not supported
RPS input	Not supported
PoE	Not supported
Long-term operating temperature [°C(°F)]	0°C to 45°C (32°F to 113°F) NOTE: When the altitude is 1800 m-5000 m (5906 ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.).
Storage temperature [°C(°F)]	–40°C to +70°C
Long-term operating relative humidity [RH]	5% to 95%, noncondensing
Long-term operating altitude [m(ft.)]	< 5000 m (16404.2 ft.)
