AX3000 M6610 with 4GE+1USB+POTS+2.4G/5G WIFI6 similar to ZTE F6610M
Overview
M6610 Optical Network Terminal (ONT) an advanced solution designed toenhance your network connectivity experience.lt combining advanced features such as 2.4G&5G WiFi, XPON technology, and FTTHcompatibility.
Whether you’re a home user or a business professional, this ONT providesreliable connectivity for seamless data transmission and communication.
Product Highlights
| Device Specifications | |||
| Ports: | 4GE+1USB+POTS+2.4G/5G WIFI | Operating temperature: | 0°C to +40C |
| Indicators: | POWE/PON/LOS/LAN/WLAN | Operating humidity: | 5%RH to 95%RH (non-condensing) |
| Power consumption | <18W | Weigh: | About 250g |
| Ratedin putrange: | 12V DC, 1.5A | Dimensions(H*W*D): | 30mm*190mm*140mm (with an external antenna) |
| RAM: | 2Gbit,DDR3 | FLASH: | 2Gbit,SPI NAND FLASH |
| Interfaces Parameters | |||
| Optical port: | 1xGPON interface(SC/APC) | Tx Power: | 0.5~5dbm |
| Receiver sensitivity: | -27dBm | Wavelengths: | US1310nm, DS1490nm |
| Transmission Distance: | 0-20km | Transmit rate: | 2.488Gbps Downstream 1.244Gbps Upstream |
| User network interface: | 4xGE | WLAN: | IEEE 802.11 b/g/n/ac Antenna gain: 5dBi WPS |
| GPON | Class B+ | ||
| Function | |||
| Supported Services: | VolP, internet | VLAN: | 802.1Q, 802.1P, 802.1ad |
| VolP: | SIP/H.248, G.711/G.729, T.30/T.38 | L3 function: | DHCP server/Client/Relay, NAT |
| Wi-Fi authentication: | WPA-PSK, WPA2-PSK, WPA-PSK+WPA2-PSK | Wi-Fi: | WPS |
| Speed: | AX3000 | Management: | Web Ul, TR069, ACS |
| Air Interface Rate： | 1200Mbps | ||
| Brand | Huawei |
|---|
