Description
| Item | OSGXGSN101 |
| Type | One-fiber bidirectional optical module, N1 |
| Operating Wavelength(nm) |
Tx: 1577 Rx: 1270 |
| Encapsulation Type | SFP+ |
| Port Rate(Gbit/s) |
Tx: 9.953 Rx: 9.953/2.488 |
| Minimum Output Optical Power(dBm) | 2 |
| Maximum Output Optical Power(dBm) | 5 |
| Maximum Receiver Sensitivity(dBm) | XG-PON channel: -27.5
XGS-PON channel: -26 |
| Optical Connector Type | SC |
| Optical Fiber Type | Single-mode |
| Overload Optical Power(dBm) | -6 |
| Extinction Ratio(dB) | 8.2 |
| Dimension(D x W x H mm) | 80x20x15 |
